Toyota Granvia/Grand Hiace
1995-08 → 2005-01 · chassis KCH1#,RCH11,VCH1#,2# · catalogue 713110 · Japan
Discontinued model
Data version 2005-07
Room Curtain & Room Rack
21 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 63301F | Plate Sub-assy, Roof Headlining Set |
| 63318D | Moulding, Sun Roof Opening Trim |
| 63407D | Bracket Sub-assy, Roof Inner Rack, RH |
| 63427 | Bracket, Roof Inner Rack, Front RH |
| 63428 | Bracket, Roof Inner Rack, Front LH |
| 65470A | Board Assy, Header |
| 65923A | Hook, Curtain, NO.1 |
| 65923B | Hook, Curtain, NO.2 |
| 65923C | Hook, Curtain, NO.3 |
| 65923D | Hook, Curtain, NO.4 |
| 65923E | Hook, Curtain |
| 65923F | Hook, Curtain, NO.5 |
| 65931 | Cover, Curtain Rail |
| 65931D | Cover, Curtain Rail |
| 65940 | Curtain Assy, Side, Front RH |
| 65950 | Curtain Assy, Side, Front LH |
| 65960 | Curtain Assy, Side, Rear RH |
| 65970 | Curtain Assy, Side, Rear LH |
| 65980 | Curtain Assy, Back Door, RH |
| 65980B | Fastner(FOR BACK DOOR GARNISH) |
| 65990 | Curtain Assy, Back Door, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
