Toyota Granvia/Grand Hiace
1995-08 → 2005-01 · chassis KCH1#,RCH11,VCH1#,2# · catalogue 713110 · Japan
Discontinued model
Data version 2005-07
Heating & Air Conditioning - Heater Unit & Blower
22 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 87029A | Cover Sub-assy, Heater Inlet Hole |
| 87103 | Motor Sub-assy, Heater Blower, W/Fan |
| 87104R | Motor Sub-assy, Rear Heater Blower |
| 87105R | Fan Sub-assy, Rear Heater Blower |
| 87106A | Servo Sub-assy, Damper |
| 87106C | Servo Sub-assy, Damper(FOR BLOWER) |
| 87107 | Unit Sub-assy, Heater Radiator |
| 87107R | Unit Sub-assy, Rear Heater |
| 87120 | Heater Assy, Rear |
| 87127A | Packing, Heater Radiator Pipe |
| 87130 | Blower Assy, Heater, Front |
| 87138 | Resistor, Heater Blower |
| 87138R | Resistor, Rear Heater Blower |
| 87150 | Radiator Assy, Heater |
| 87187A | Wire, Blower Motor Lead |
| 87190C | Switch Assy, Temperature Control |
| 87201D | Duct Sub-assy, Air |
| 87212A | Duct, Air, Rear NO.1 |
| 87215H | Duct, Air, Rear NO.3 |
| 88625L | Thermistor, Cooler |
| 88750A | Transistor Assy, Blower Resistor |
| 88897R | Aspirator |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
