Toyota Alphard HV
2003-07 → 2008-04 · chassis ATH10 · catalogue 715110 · Japan
Supported model
Data version 2008-10
Seat Belt
26 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73200A | Adjuster Assy, Front Shoulder Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73350 | Belt Assy, Rear Seat Lap Type, Center |
| 73350C | Belt Assy, Rear Seat, Outer Center |
| 73360B | Belt Assy, Rear Seat, Outer |
| 73360C | Belt Assy, Rear NO.1 Seat, Outer RH |
| 73370B | Belt Assy, Rear Seat, Outer |
| 73370C | Belt Assy, Rear NO.1 Seat, Outer LH |
| 73371 | Hanger, Rear Seat Shoulder Belt, RH |
| 73371C | Hanger, Rear NO.2 Seat Shoulder Belt, RH |
| 73372 | Hanger, Rear Seat Shoulder Belt, LH |
| 73372C | Hanger, Rear NO.2 Seat Shoulder Belt, LH |
| 73380 | Belt Assy, Rear Seat 3 Point Type, Inner, RH |
| 73380A | Belt Assy, Rear Seat, Inner |
| 73390 | Belt Assy, Rear Seat 3 Point Type, Inner, LH |
| 73390C | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73540C | Belt Assy, Rear NO.2 Seat Lap Type |
| 73550 | Belt Assy, Rear NO.2 Seat Lap Type, Center |
| 73560 | Belt Assy, Rear NO.2 Seat, Outer RH |
| 73570 | Belt Assy, Rear NO.2 Seat, Outer LH |
| 73580 | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73590 | Belt Assy, Rear NO.2 Seat, Inner LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
