Toyota Hiace Quick Delivery
1985-08 → 1995-05 · chassis LH8# · catalogue 721120 · Japan
Discontinued model
Data version 1995-11
Roof Panel & Back Panel
25 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55501A | Door Sub-assy, Glove Compartment |
| 55517A | Stopper, Glove Compartment Door |
| 55561B | Striker, Glove Compartment Door Lock |
| 63102A | Panel Sub-assy, Windshield Header |
| 63103C | Reinforcement Sub-assy, Roof Panel |
| 63104D | Reinforcement Sub-assy, Roof Panel, NO.2 |
| 63105F | Reinforcement Sub-assy, Roof Panel, NO.3 |
| 63106 | Reinforcement Sub-assy, Roof Panel, NO.4 |
| 63111B | Panel, Roof, NO.1 |
| 63112A | Panel, Roof, NO.2 |
| 63113A | Panel, Roof, NO.3 |
| 63115A | Panel, Roof, NO.5 |
| 63252G | Strength, Roof Panel, Center NO.2 |
| 63255E | Strength, Roof Panel, Center NO.5 |
| 63271C | Strength, Roof Panel, NO.1 RH |
| 63272A | Strength, Roof Panel, NO.2 RH |
| 63273H | Strength, Roof Panel, NO.3 |
| 63274B | Strength, Roof Panel, NO.4 RH |
| 63275B | Strength, Roof Panel, NO.5 |
| 63276B | Strength, Roof Panel, NO.6 RH |
| 63277F | Strength, Roof Panel, NO.7 RH |
| 63282E | Strength, Roof Panel, NO.2 LH |
| 63665A | Mat, Roof Console Box |
| 64013A | Rail Sub-assy, Back |
| 64101D | Rail Sub-assy, Upper Back, Outer |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
