Toyota Quick Delivery
1995-05 → 2001-08 · chassis BU68,LH81,82,LY151,152,RZU68 · catalogue 721130 · Japan
Discontinued model
Data version 2002-01
Hood & Front Fender
10 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 53301 | Hood Sub-assy |
| 53382 | Bumper, Hood, Front |
| 53383C | Seal, Hood TO Cowl Top |
| 53384A | Bumper, Fender TO Hood |
| 53385B | Bracket, Fender TO Hood Bumper, RH |
| 53386B | Bracket, Fender TO Hood Bumper, LH |
| 53835A | Brace, Front Fender TO Apron, RH |
| 53836A | Brace, Front Fender TO Apron, LH |
| 76110 | Pole Assy, Fender, RH |
| 76120 | Pole Assy, Fender, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
