Toyota Quick Delivery
1995-05 → 2001-08 · chassis BU68,LH81,82,LY151,152,RZU68 · catalogue 721130 · Japan
Discontinued model
Data version 2002-01
Instrument Panel & Glove Compartment
38 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55295 | Stay, Table, NO.1 |
| 55295A | Clip(FOR TABLE STAY) |
| 55301 | Panel Sub-assy, Instrument |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303D | Panel Sub-assy, Instrument, Front |
| 55305D | Panel Sub-assy, Instrument, Rear |
| 55358B | Protector, Knee |
| 55366A | Bracket, Radio Mounting, NO.1 |
| 55368A | Bracket, Radio Mounting, NO.2 |
| 55403 | Hood Sub-assy, Meter |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55412E | Clip, Panel, Instrument Cluster Finish, End |
| 55448B | Cover, Oil Reservoir Tank, RH |
| 55510 | Door Assy, Glove Compartment |
| 55521C | Cover, Stereo Opening |
| 55537A | Cover, Throttle Knob Hole |
| 55539 | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55565B | Knob, Glove Compartment Door Lock |
| 55573A | Hinge, Glove Compartment Door |
| 55581A | Compartment, Glove |
| 55602 | Stay Sub-assy, Steering Column, Upper |
| 55623 | Catch, Oil Reservoir Tank Cover |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55661 | Clamp, Steering Column, Upper |
| 55662 | Clamp, Steering Column, Lower |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55670A | Register Assy, Instrument Panel, Center |
| 55680 | Register Assy, Instrument Panel, Lower NO.1 |
| 55691A | Plate, Air Damper Control Name, NO.1 |
| 55950 | Nozzle Assy, Defroster |
| 55950B | Nozzle Assy, Defroster, RH |
| 55953A | Register, Defroster, Center |
| 55953C | Register, Defroster, Center |
| 55960 | Nozzle Assy, Defloster, LH |
| 55971A | Duct, Side Defroster Nozzle, NO.1 |
| 56500 | Cabinet Assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
