Toyota Quick Delivery
1995-05 → 2001-08 · chassis BU68,LH81,82,LY151,152,RZU68 · catalogue 721130 · Japan
Discontinued model
Data version 2002-01
Front Turn Signal Lamp
10 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 81510 | Lamp Assy, Front Turn Signal, RH |
| 81510B | Bulb (FOR FRONT TURN SIGNAL LAMP) |
| 81511 | Lens, Front Turn Signal Lamp, RH |
| 81512 | Gasket, Front Turn Signal Lamp Lens, RH |
| 81513A | Unit Assy, Front Turn Signal Lamp, RH |
| 81515A | Plug Assy, Front Turn Signal Lamp |
| 81520 | Lamp Assy, Front Turn Signal, LH |
| 81521 | Lens, Front Turn Signal Lamp, LH |
| 81522 | Gasket, Front Turn Signal Lamp Lens, LH |
| 81523A | Unit Assy, Front Turn Signal Lamp, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
