Toyota Quick Deli/Urban Sup

1999-08 → 2011-09 · chassis BU28#,LY228,270,RZU280,XZU28#,XKU280 · catalogue 721140 · Japan

Discontinued model Data version 2013-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate

19 part groups · 2 illustrations

Illustrations

Figure 740662I 740662I 1999-08 → — Figure 742073D 742073D 1999-08 → —

Part groups

PNCDescription
17792C Label, Engine Vacuum Hose Information
17792D Label, Emission Control Device Information
28897A Plate, Battery Caution
36369 Label, Transfer Information
47398A Label, Hill Holder Caution
74511B Plate, Name
74517 Plate, Exhaust Temperature Caution
74529A Plate, Back Door Caution
74544D Plate, Tire Carrier Caution
74559B Label, Fuel Information
74562 Plate, Emission Control System Information
74562B Label, Emission Information
74565A Label, Hand Truck Information
74574 Plate, Noise Identification
74582D Label, Safety Caution
74587 Label, License Plate Lamp Notice
74599A Plate, Separation Door Open Caution
74751 Label, Tire Pressure Information
88723H Label, Cooler Service Caution
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
