Toyota Quick Delivery 200
2012-03 → 2012-12 · chassis XZU282 · catalogue 721150 · Japan
Supported model
Data version 2013-07
Separator & Separator Curtain
21 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 66301D | Hook Sub-assy, Rope |
| 66318A | Band, Rope Hook |
| 66319 | Plate, Rope Hook |
| 74804B | Bar Sub-assy, Separator Vertical, LH |
| 74807A | Bar Sub-assy, Rear Separator |
| 74812D | Bar, Separator, NO.2 |
| 74813A | Bracket, Separator |
| 74822E | Retainer, Separator Bar |
| 74831C | Pipe, Front Protector, Center |
| 74850B | Separator Sub-assy, Rear |
| 74854A | Stop, Separator |
| 74854C | Stop, Separator |
| 74858A | Bracket, Separator Bar, Upper |
| 74860B | Separator Assy, Rear LH |
| 74863E | Rod, Separator |
| 74864B | Shaft, Separator |
| 74864D | Shaft, Separator |
| 74865B | Cover, Center Protector |
| 74867E | Spacer, Separator, NO.1 |
| 74873A | Bracket, Separator, Lower, NO.1 |
| 74899A | Handle, Separator |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
