Toyota Toyoace

1979-03 → 1985-07 · chassis RY2#,3#,LY2#,3#,JY30,BY3# · catalogue 731130 · Japan

Discontinued model Data version 1986-05

Rear Body Guard Frame & Tail Gate

44 part groups · 5 illustrations

PNC	Description
64119	Guard, Back Window, NO.2
65203	Bracket Sub-assy, Gate Bumper, RH
65204	Bracket Sub-assy, Gate Bumper, LH
65301A	Guard Sub-assy, Bezel, Front
65400	Frame Assy, Rear Body Guard
65410	Panel Assy, Rear Body, Front
65436	Hook, Guard Frame
65446	Insulator, Header Board
65462	Hook, Tarpaulin
65475	Panel, Front Cover
65491	Weatherstrip, Front Panel Window
65492	Wedge, Front Panel Window Weatherstrip
65493	Weatherstrip, Front Cover Panel
65494	Glass, Front Panel Window
65582A	Anti-rattler, Support Corner
65614	Strip, Tail Gate Hinge, Inside
65679B	Seal, Tail Gate
65700	Gate Assy, Rear Body Tail
65702	Board Sub-assy, Tail Gate
65723	Panel, Tail Gate
65725	Panel, Tail Gate Side
65735	Hinge, Tail Gate Male
65951	Clamp, Shovel
66110	Hinge Assy, Tail Gate
66110A	Pin, Tail Gate Hinge
66121	Hinge, Tail Gate, Male
66125	Hinge, Tail Gate, Female
66161	Handle, Side Gate Latch, RH
66162	Handle, Side Gate Latch, LH
66164	Handle, Tail Gate Latch, RH
66165	Handle, Tail Gate Latch, LH
66166	Cap, Gate Latch Handle
66170	Latch Assy, Rear Body Tail Gate
66217	Pin, Tail Gate Latch
66218	Bracket, Tail Gate Latch Pin
66219	Stay, Tail Gate Latch Pin Bracket
66280	Chain Assy, Tail Gate, RH
66290	Chain Assy, Tail Gate, LH
66321A	Bumper, Gate Rubber
66350	Handle Assy, Support Corner
66411	Bracket, Guard Frame, RH
66412	Bracket, Guard Frame, LH
66701	Support Sub-assy, Side Gate, RH
66702	Support Sub-assy, Side Gate, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
