Toyota Dyna/Toyoace
2001-07 → present · chassis KDY2##,LY2##,RZY2##,TRY2## · catalogue 731170 · Japan
Discontinued model
Data version 2016-10
Roof Panel & Back Panel
46 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 58993C | Bracket, Console Box Mounting, Rear |
| 63071 | Frame Sub-assy, Back Door Opening, Upper |
| 63103A | Reinforcement Sub-assy, Roof Panel |
| 63105E | Reinforcement Sub-assy, Roof Panel, NO.3 |
| 63109C | Retainer Sub-assy, Roof Reinforcement |
| 63111 | Panel, Roof |
| 63112B | Panel, Roof, Rear |
| 63129A | Cushion, Roof Reinforcement |
| 63132 | Panel, Windshield Header, Inner |
| 63141G | Reinforcement, Roof Panel, NO.1 |
| 63141J | Reinforcement, Roof Panel |
| 63142 | Reinforcement, Roof Panel, NO.2 |
| 63142A | Reinforcement, Roof Panel, NO.2 |
| 63145B | Reinforcement, Windshield Header Panel |
| 63146A | Bracket, Roof Panel Reinforcement, NO.1 |
| 63151B | Seal, Roof Panel Reinforcement |
| 63153B | Shim, Roof Reinforcement |
| 63209 | Panel Sub-assy, Roof Wind Deflector |
| 63212B | Panel, Roof Wind Deflector |
| 63213B | Panel, Sliding Roof, Inner |
| 63223B | Bracket, Roof Wind Deflector, RH |
| 63224B | Bracket, Roof Wind Deflector, LH |
| 63230B | Panel Assy, Roof Wind Deflector |
| 63231 | Bracket, Room Lamp |
| 63273R | Packing, Roof Window Defrector |
| 63332D | Pad, Sun Roof Headlining |
| 63701A | Bracket Sub-assy, Roof Air Deflector, Front |
| 63703 | Bar Sub-assy, Roof Air Deflector, NO.1 |
| 63713 | Bracket, Roof Panel Reinforcement, NO.3 |
| 63714 | Bracket, Roof Panel Reinforcement, NO.4 |
| 63765A | Bracket, Roof Air Deflector, RH |
| 63766A | Bracket, Roof Air Deflector, LH |
| 63776 | Bar, Roof Air Deflector, NO.2 |
| 63781 | Stay, Roof Air Deflector |
| 64111A | Panel, Back |
| 64115B | Reinforcement, Back Panel |
| 64117A | Reinforcement, Cab Back, Lower |
| 64122A | Baffle, Dust Rear Body |
| 64145E | Bracket, Rear Seatback Set |
| 64149B | Retainer, Back Panel Headrest |
| 64225A | Hanger, Rear Seat Cushion Support |
| 64277E | Bracket, Back Panel Trim, Lower |
| 64811 | Glass, Back Window |
| 64811G | Cover, Back Window |
| 64831 | Weatherstrip, Back Window Glass |
| 64832 | Key, Back Window Weatherstrip |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
