Toyota Dyna
2021-08 → present · chassis GDY231,281,TRY230 · catalogue 731180 · Japan
Supported model
Data version 2021-08
Switch & Relay & Computer
120 part groups · 12 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 17616A | Relay, Air Pump |
| 28300 | Relay Assy, Starter |
| 28371C | Relay, Ignition, NO.2 |
| 28551 | Controller, Glow Plug |
| 28559 | Bracket, Glow Plug Controller, NO.1 |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 46453C | Bracket, Holder |
| 55173F | Bracket, Electrical Part |
| 55173G | Bracket, Electrical Part, NO.2 |
| 81713 | Holder, Fusee |
| 82210P | Engine Room Fusible Link |
| 82600D | Instrument Panel Fuse |
| 82600E | Engine Room Fuse |
| 82600G | Plate, Caution(FOR FUSE) |
| 82616 | Puller, Fuse |
| 82620A | Block Assy, Fusible Link |
| 82620C | Clip |
| 82660B | Block Assy, Relay |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82663 | Cover, Relay Block, Lower |
| 82715 | Bracket,Wiring Harness Clamp |
| 82715W | Bracket, Wiring Harness Clamp |
| 82730 | Block Assy, Instrument Panel Junction |
| 82741 | Block, Engine Room Relay |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83390 | Switch Assy, Vacuum Warning |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 84052 | Switch Assy, Un-lock Warning |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84150D | Switch Assy, Headlamp Cleaner |
| 84152 | Switch, Headlamp Leveling |
| 84153 | Switch, Auto High Beam |
| 84172 | Switch, Room Lamp |
| 84210 | Switch Assy, Back-up Lamp |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84234A | Bracket, Courtesy Lamp Switch (FOR REAR DOOR) |
| 84236B | Cover, Courtesy Lamp Switch |
| 84270A | Switch Assy, Mirror Heater |
| 84270K | Switch Assy, Dpr |
| 84306 | Cable Sub-assy, Spiral |
| 84307 | Cable Sub-assy, Spiral W/Sensor |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84450 | Switch Assy, Ignition OR Starter |
| 84453 | Switch, Idle UP |
| 84490J | Switch Assy, Clearance Sonar |
| 84512 | Switch, Tilt Cab Control |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84640C | Switch Assy, Exhaust Retarder |
| 84650 | Switch Assy, Windshield Wiper |
| 84656A | Bezel, Switch |
| 84731R | Knob, Rear Heater Blower Switch |
| 84732A | Switch, Rear Heater Blower |
| 84770A | Switch Assy, Pre-collision System Cancel |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84810G | Switch Assy, Power Window Regulator, Rear NO.2 |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84873A | Switch, Retractable Outer Mirror |
| 84988L | Switch, Vsc Off |
| 85432 | Solenoid, Key Interlock |
| 85500 | Lighter Assy, Cigarette |
| 85513 | Cover, Cigarette Lighter |
| 85520 | Knob And Element Assy, Cigarette Lighter |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85900Q | Relay, Tail |
| 85910 | Relay Assy, Circuit Opening |
| 85910E | Relay, Injector |
| 85915 | Relay, Main |
| 85916P | Relay, Headlamp |
| 85916U | Relay, Headlamp, NO.2 |
| 85917D | Relay, Heater(FOR AIR FUEL RATIO SENSOR) |
| 85930G | Relay, Acc |
| 85933 | Computer, Shift Lock Control |
| 85941 | Relay, Windshield Washer |
| 85942 | Relay, Headlamp Cleaner Control |
| 86650B | Buzzer Assy, Reverse Warning |
| 87299 | Relay, Heater |
| 87346K | Relay, Ptc Heater |
| 88280A | Switch Assy, Clutch |
| 88310C | Relay, Air Conditioner Compressor |
| 88610N | Switch Assy, Cooler Control |
| 88790F | Thermistor Assy |
| 89111 | Computer, Network Gateway |
| 89120A | Sensor, Automatic Light Control |
| 89129 | Bracket, Conlight Scanner |
| 89221B | Computer, Body |
| 89245B | Sensor, Steering |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89425A | Sensor, Exhaust Gas Temperature, NO.2 |
| 89425B | Sensor, Exhaust Gas Temperature, NO.3 |
| 89425C | Sensor, Exhaust Gas Temperature, NO.4 |
| 89425D | Sensor, Exhaust Gas Temperature, NO.5 |
| 89437 | Cover, Sensor |
| 89463B | Relay, Nitrogen Oxides |
| 89463C | Sensor, Nitrogen Oxides, NO.1 |
| 89463D | Sensor, Nitrogen Oxides, NO.2 |
| 89465 | Sensor, Oxygen |
| 89467B | Sensor, Air Fuel Ratio |
| 8946A | Bracket, Exhaust Sensor Clamp |
| 89481B | Sensor, Differential Pressure |
| 89491 | Sensor, Engine Oil Level |
| 89491A | Gasket, Engine Oil Level Sensor |
| 894A1 | Sensor, Particulate Matter |
| 89539E | Bracket, Computer |
| 89539Q | Bracket, Computer |
| 89559 | Bracket, Emission Control Computer |
| 89615 | Sensor, Knock Control |
| 89677A | Bracket, Urea Pump Control, NO.1 |
| 89678A | Bracket, Urea Pump Control, NO.2 |
| 896B1 | Computer, Urea Pump Control |
| 896B1A | Relay, Dcu Main |
| 89870E | Relay, Electronic Driver Unit |
| 89940 | Computer Assy, Headlamp Swivel |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
