Toyota Dyna/Toyoace

1984-09 → 1987-08 · chassis BU6#,7#,8#,9# · catalogue 751130 · Japan

Discontinued model Data version 1988-01

Caution Plate

34 part groups · 2 illustrations

PNC	Description
33621A	Plate, Control Lever Caution
35518	Plate, Automatic Transmission Caution, NO.2
35519	Plate, Automatic Transmission Caution
65539	Plate, Side Gate Caution
74517	Plate, Exhaust Temperature Caution
74519	Plate, Fuel Caution
74533	Plate, Transfer Caution
74534	Plate, Damp Caution
74538A	Plate, Air Cleaner Inlet Operational Caution
74541	Plate, Tire Pressure Caution
74551B	Plate, Rear NO.2 Seat Caution
74552	Plate, Safety Caution
74555	Plate, Dump Lever Caution
74555A	Plate, Dump Lever Lock Caution
74556	Plate, Grease Caution
74557	Plate, Roof Ventilation Caution
74562	Plate, Emission Control System Information
74563	Plate, Emission Control Device Identification
74565	Plate, Tire Carrier Caution
74566B	Plate, Power Take Off Caution
74566C	Plate, Front Slide Door Caution
74566D	Label, Power Take Off Valve Link Cover Caution
74567B	Plate, Front Slide Door Arm Caution
74568A	Plate, Front Slide Door Caution, NO.2
74571	Plate, Brake Fluid Caution
74574	Plate, Noise Identification
74581	Plate, Power Steering Caution
74582A	Plate, Safety Caution
74583	Plate, Seat Suspension Caution
74585	Plate, Tire Carrier Caution, NO.2
74586	Plate, Tire Carrier Caution, NO.3
74859A	Plate, Caution, Rear Separator
75476A	Plate, Tilt Operational Caution
75477A	Plate, Tilt Operational Caution, NO.2

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
