Toyota Dyna/Toyoace

1988-08 → 1995-05 · chassis BU6#,7#,8#,9# · catalogue 751150 · Japan

Discontinued model Data version 1995-11

Cab Mounting & Body Mounting

41 part groups · 3 illustrations

PNC	Description
52201B	Cushion Sub-assy, Cab Front Mounting
52203D	Cushion Sub-assy, Cab Mounting, NO.2 Upper
52203E	Cushion Sub-assy, Cab Mounting, NO.2
52204B	Cushion Sub-assy, Cab Mounting, NO.2 Lower
52211G	Spacer, Cab Front Mounting
52216A	Stopper, Cab Mounting Cushion
52222A	Spacer, Cab Rear Mounting, Upper
52243	Support, Cab Mounting Cushion
52306A	Bracket Sub-assy, Cab Mounting Hook, NO.1
52307A	Bracket Sub-assy, Cab Mounting Hook, NO.2
52367	Hook, Cab Rear Mounting
52887	Union, Tilt Cab Cylinder
52887A	Union, Tilt Cab Cylinder
53825B	Bracket, Rear Lock Handle Rod
53887C	Plate, Front Mudguard
54870	Pump Assy, Tilt Cab
54880	Valve Assy, Tilt Cab Pump
54881	Hose, Tilt Cab Pump Pressure
54882	Hose, Tilt Cab Pump Return
54883	Hose, Tilt Cab Pump
54884	Case, Tilt Cab Pump Valve
54885	Valve, Tilt Cab Down Stop
54886	Valve, Tilt Cab Down Safety
54887	Union, Tilt Cab Cylinder
54888	Valve, Tilt Cab Pump, NO.1
54889	Valve, Tilt Cab Pump, NO.2
54890	Pump Assy, Tilt Cab Hand
54891	Bracket, Tilt Cab Hand Pump
54907	Pipe Sub-assy, Tilt Cab Lock Connecting
54930	Bracket Assy, Tilt Cab Coil Spring, Lower
54938	Plate, Tilt Cab Coil Spring Support
54940	Stay Assy, Tilt Cab
54960	Spring Assy, Tilt Cab Coil
54960A	Cylinder Assy, Tilt Cab
54970	Latch Assy, Tilt Cab Stopper
54980	Lock Assy, Tilt Cab Mounting, RH
54990	Lock Assy, Tilt Cab Mounting, LH
57871A	Bracket, Tilt Cab Pump
58954	Cover, Rear Lock Handle Grip
58959	Rod, Rear Lock, Handle Latch
66443A	Cushion, Rear Floor Spacer

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
