Toyota Dyna 200/Toyoace G25
1995-05 → 2000-05 · chassis BU1##,2##,RZU100,140,XZU130,140 · catalogue 751160 · Japan
Discontinued model
Data version 2001-01
Camera & Rear Monitor Display
13 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 86028 | Bracket Sub-assy, Television |
| 86029 | Bracket Set, Television |
| 86110 | Multi-display Assy |
| 86111B | Display, Multi-display |
| 86170B | Switch & Volume Assy, Television |
| 86291 | Bracket, Television |
| 86709 | Bracket Set, Television Camera |
| 86790 | Camera Assy, Television |
| 86791 | Bracket, Television Camera |
| 86793 | Spacer, Camera Bracket |
| 86794 | Cover, Television Camera Wire |
| 86794A | Cover, Television Camera Wire, NO.2 |
| 86799 | Wire, Television Camera |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
