Toyota Dyna/Toyoace

2006-10 → 2011-06 · chassis BZU3##,TRU3##,500,XZU3##,5## · catalogue 751180 · Japan

Discontinued model Data version 2012-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Ignition Coil & Spark Plug / Glow Plug

17 part groups · 3 illustrations

Illustrations

Figure 192829B 192829B 2007-05 → — Figure 192827B 192827B 2007-05 → — Figure 192672C 192672C 2006-10 → —

Part groups

PNCDescription
19100P Plug, Spark
19500 Coil Assy, Ignition
19531 Holder, Resistive Cord, NO.1
19532 Holder, Resistive Code, NO.2
19539 Holder, Resistive Code, NO.4
19539A Holder, Resistive Code, NO.5
19539B Holder, Resistive Code, NO.6
19850 Plug Assy, Glow
19850B Grommet, Screw(FOR GLOW PLUG)
19879 Wire, Glow Plug Ground
19901 Cord Set, Coil & Spark, W/Resistive
19901A Cord, Coil Resistive
19901B Cord, Spark Plug Resistive, NO.1
19901C Cord, Spark Plug Resistive, NO.2
19901D Cord, Spark Plug Resistive, NO.3
19901E Cord, Spark Plug Resistive, NO.4
28626 Wire, Glow Plug
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
