Toyota Dyna
2021-03 → present · chassis XZC6##,XZU6## · catalogue 7511A0 · Japan
Supported model
Data version 2021-03
Side Member
96 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 51793C | Bracket, Side Step, NO.1 RH |
| 51794B | Bracket, Side Step, NO.1 LH |
| 51795B | Bracket, Side Step, NO.2 RH |
| 51796A | Bracket, Side Step, NO.2 LH |
| 53805A | Shield Sub-assy, Fender Splash, Front RH |
| 53806A | Shield Sub-assy, Fender Splash, Front LH |
| 53827G | Protector, Front Fender Side Panel, RH |
| 53828H | Protector, Front Fender Side Panel, LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61027A | Pillar Sub-assy, Front Body, Outer RH |
| 61028A | Pillar Sub-assy, Front Body, Outer LH |
| 61035 | Bracket Sub-assy, Instrument Panel TO Cowl Side, RH |
| 61035C | Retainer Sub-assy, Pillar Lower Hinge, RH |
| 61036D | Retainer Sub-assy, Pillar Lower Hinge, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61148 | Extension, Front Body Pillar, Outer LH |
| 61163B | Pillar, Front Body, Lower Inner RH |
| 61164 | Pillar, Front Body, Inner LH |
| 61182C | Bracket, Instrument Side, LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61233A | Rail, Roof Side, Inner NO.2 RH |
| 61234A | Rail, Roof Side, Inner NO.2 LH |
| 61245 | Reinforcement, Roof Side Rail, Outer RH |
| 61246 | Reinforcement, Roof Side Rail, Outer LH |
| 61247B | Reinforcement, Roof Side Rail, Inner RH |
| 61248B | Reinforcement, Roof Side Rail, Inner LH |
| 61263B | Channel, Roof Drip Side, Front RH |
| 61264A | Channel, Roof Drip Side, Front LH |
| 61303 | Reinforce Sub-assy, Center Body Pillar, Upper RH |
| 61304 | Reinforce Sub-assy, Center Body Pillar, Upper LH |
| 61308B | Retainer Sub-assy, Door Lock Striker, RH |
| 61309B | Retainer Sub-assy, Door Lock Striker, LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61321 | Reinforcement, Center Body Pillar, Upper RH |
| 61322 | Reinforcement, Center Body Pillar, Upper LH |
| 61335D | Retainer, Seat Belt Anchor |
| 61335E | Retainer, Seat Belt Anchor |
| 61343A | Pillar, Center Body, Inner RH |
| 61344A | Pillar, Center Body, Inner LH |
| 61347A | Reinforcement, Belt Anchor TO Center Pillar, RH |
| 61348A | Reinforcement, Belt Anchor TO Center Pillar, LH |
| 61395 | Seal, Center Body Pillar, RH |
| 61396B | Seal, Center Body Pillar, LH |
| 61423A | Panel, Fender, Inner Lower RH |
| 61424A | Panel, Fender, Inner Lower LH |
| 61451B | Plate, Step, Lower RH |
| 61452C | Plate, Step, Lower LH |
| 61453A | Panel, Rocker Inner, Rear RH |
| 61455A | Retainer, Front Step, RH |
| 61456B | Retainer, Front Step, LH |
| 61463A | Panel, Rocker, Inner Rear LH |
| 61478C | Bracket, Mudguard, Front RH |
| 61479C | Bracket, Front Mudguard |
| 61479D | Bracket, Front Mudguard |
| 61488C | Bracket, Mudguard, Front LH |
| 61503B | Reinforcement Sub-assy, Quarter Lock Pillar, RH |
| 61504B | Reinforcement Sub-assy, Quarter Lock Pillar, LH |
| 61515B | Extension, Quarter Lock Pillar, RH |
| 61516 | Extension, Quarter Lock Pillar, LH |
| 61525A | Retainer, Separator Bar Bracket, RH |
| 61526A | Retainer, Separator Bar Bracket, LH |
| 61575B | Plate, Cab Rear Pillar, Upper RH |
| 61576 | Plate, Cab Rear Pillar, Upper LH |
| 61661D | Extension, Quarter Panel TO Upper Back, RH |
| 61662B | Extension, Quarter Panel TO Upper Back, LH |
| 61737G | Reinforcement, Roof Side, Inner RH |
| 61738E | Reinforcenent, Roof Side, Inner LH, NO.2 |
| 61768A | Reinforcement, Seat Belt Anchor, NO.2 RH |
| 61769A | Reinforcement, Seat Belt Anchor, NO.2 LH |
| 63147E | Bracket, Roof Panel Reinforcement |
| 63147G | Bracket, Roof Panel Reinforcement |
| 63147L | Bracket, Roof Panel Reinforcement |
| 63148G | Reinforcement, Roof Panel Side |
| 63365B | Plate, Roof Headlining Set |
| 63365C | Plate, Roof Headlining Set |
| 63369B | Bracket, Roof Silencer, Side |
| 63369F | Bracket, Roof Silencer, Side |
| 64015 | Panel Sub-assy, Back Corner, Inner RH |
| 64016 | Panel Sub-assy, Back Corner, Inner LH |
| 64103A | Panel Sub-assy, Back Corner, Outer RH |
| 64104A | Panel Sub-assy, Back Corner, Outer LH |
| 64147C | Plate, Back Panel Corner, Upr RH |
| 64148A | Plate, Back Panel Corner, Upper LH |
| 64165C | Cover, Back Corner, Inner Rear |
| 64169A | Protector, Fuel Inlet |
| 64726R | Clip, Roof Side Panel |
| 74657E | Bracket, Hand Rail, NO.1 |
| 74657F | Bracket, Hand Rail, NO.1 |
| 74665 | Retainer, Hand Rail Bar, Upper RH |
| 74669 | Retainer, Hand Rail |
| 74773 | Bracket, Hand Grip, Lower |
| 74773A | Bracket, Hand Grip, Lower |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
