Toyota Dyna
2021-03 → present · chassis XZC6##,XZU6## · catalogue 7511A0 · Japan
Supported model
Data version 2021-03
Switch & Relay & Computer
171 part groups · 16 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 28300 | Relay Assy, Starter |
| 28300D | Relay, Starter Cut |
| 28371 | Relay, Ignition, NO.1 |
| 28490B | Relay, Power Take-off Signal Reverse |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 46453C | Bracket, Holder |
| 55173A | Bracket |
| 55173F | Bracket, Electrical Part |
| 55173G | Bracket, Electrical Part, NO.2 |
| 81713 | Holder, Fusee |
| 81935B | Cord Assy, Oil Pan Heater |
| 82210P | Engine Room Fusible Link |
| 82600D | Instrument Panel Fuse |
| 82600E | Engine Room Fuse |
| 82600G | Plate, Caution(FOR FUSE) |
| 82616 | Puller, Fuse |
| 82620A | Block Assy, Fusible Link |
| 82620C | Clip |
| 82641 | Relay, Integration NO.1 |
| 82642B | Relay, Day Time Running Light, NO.1 |
| 82660B | Block Assy, Relay |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82663 | Cover, Relay Block, Lower |
| 82715 | Bracket,Wiring Harness Clamp |
| 82715Z | Bracket, Wiring Harness Clamp |
| 82730A | Block Assy, Driver Side Junction |
| 82741 | Block, Engine Room Relay |
| 82823K | Cap, Terminal |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83380 | Switch Assy, Presure |
| 83380A | Switch Assy, Pressure |
| 83380B | Switch Assy, Pressure, NO.1 |
| 83380C | Switch Assy, Pressure, NO.2 |
| 83380D | Switch Assy, Pressure, NO.3 |
| 83380E | Switch Assy, Pressure, NO.6 |
| 83380F | Switch Assy, Pressure, NO.7 |
| 83380G | Switch Assy, Pressure, NO.8 |
| 83390 | Switch Assy, Vacuum Warning |
| 83420 | Gage Assy, Water Temperature Sender |
| 83420A | Gage Assy, Oil Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 83950M | Lamp Assy, Telltale |
| 84052 | Switch Assy, Un-lock Warning |
| 84113A | Bracket, Switch, NO.1 |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84150D | Switch Assy, Headlamp Cleaner |
| 84152 | Switch, Headlamp Leveling |
| 84160 | Switch Assy, Room Lamp |
| 84210 | Switch Assy, Back-up Lamp |
| 84220C | Switch Assy, Transmission Position Indicator |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84234A | Bracket, Courtesy Lamp Switch (FOR REAR DOOR) |
| 84236B | Cover, Courtesy Lamp Switch |
| 84247A | Switch, Steering Pad, LH |
| 84270A | Switch Assy, Mirror Heater |
| 84270B | Switch Assy, Brake Lock |
| 84270D | Switch Assy, ES Start Timing |
| 84270K | Switch Assy, Dpr |
| 84270L | Switch Assy, Idle Stop |
| 84280A | Switch Assy, Generally Usa, Toggle Type |
| 84290 | Switch Assy, Limit |
| 84290E | Switch Assy, Limit |
| 84306 | Cable Sub-assy, Spiral |
| 84307 | Cable Sub-assy, Spiral W/Sensor |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84450 | Switch Assy, Ignition OR Starter |
| 84480 | Switch Assy, Main |
| 84490J | Switch Assy, Clearance Sonar |
| 84512 | Switch, Tilt Cab Control |
| 84512B | Relay, Tilt Cab Control |
| 84513A | Bracket, Tilt Cab Starter Switch |
| 84513B | Bracket, Tilt Cab Starter Switch |
| 84520B | Relay, Clutch Start |
| 84520C | Relay, Neutral Signal Reverse |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84580E | Switch Assy, Throttle Position |
| 84640C | Switch Assy, Exhaust Retarder |
| 84650 | Switch Assy, Windshield Wiper |
| 84656A | Bezel, Switch |
| 84724 | Switch, 4 Wheel Drive Control |
| 84731R | Knob, Rear Heater Blower Switch |
| 84732A | Switch, Rear Heater Blower |
| 84770A | Switch Assy, Pre-collision System Cancel |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84810G | Switch Assy, Power Window Regulator, Rear NO.2 |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84873A | Switch, Retractable Outer Mirror |
| 84986C | Switch, Vsc Off |
| 85432 | Solenoid, Key Interlock |
| 85440B | Relay(FOR FOUR WHEEL DRIVE CONTROL) |
| 85500 | Lighter Assy, Cigarette |
| 85513 | Cover, Cigarette Lighter |
| 85520 | Knob And Element Assy, Cigarette Lighter |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85530D | Socket Assy, Power Outlet, NO.2 |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85535E | Cover, Power Outlet Socket, NO.2 |
| 85900 | Relay Assy, Control Unit |
| 85900C | Relay Assy, Control Unit (FOR BRAKE LOCK) |
| 85900E | Relay, Idle Stop |
| 85900F | Relay, Battery Switch |
| 85900H | Relay Assy, Control Unit(FOR TILT CAB) |
| 85900J | Relay, Brake Lock |
| 85900K | Relay Assy, Control Unit (FOR ELECTRIC PARKING BRAKE) |
| 85900Q | Relay, Tail |
| 85909A | Bracket Sub-assy, Relay Block |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85911P | Relay, Actuator Power |
| 85912D | Relay |
| 85916C | Relay, Back UP Lamp |
| 85916P | Relay, Headlamp |
| 85916U | Relay, Headlamp, NO.2 |
| 85919E | Relay, Stop Lamp |
| 85930G | Relay, Acc |
| 85931B | Relay, Fuel Heater |
| 85933 | Computer, Shift Lock Control |
| 85934 | Relay, Magnet-clutch |
| 85934A | Relay Condenser Fan |
| 85934B | Relay, Idle Stop |
| 85941 | Relay, Windshield Washer |
| 85942 | Relay, Headlamp Cleaner Control |
| 85999H | Bracket, Relay |
| 86206D | Converter Sub-assy, Voltage |
| 86210E | Converter Assy, Voltage |
| 86245C | Bracket, Voltage Converter |
| 86245D | Bracket, Voltage Converter, NO.2 |
| 86245E | Bracket, Voltage Converter, NO.3 |
| 86245F | Bracket, Voltage Converter, NO.4 |
| 86650E | Buzzer Assy |
| 86650H | Buzzer Assy, Back |
| 86650P | Buzzer Assy, Tilt Warning |
| 87190F | Switch Assy, Temperature Control |
| 87290F | Switch Assy, Eco |
| 88150A | Computer Assy, Driving Support |
| 88610N | Switch Assy, Cooler Control |
| 88625M | Thermistor, Cooler |
| 89050 | Computer Assy, Parking Brake |
| 89120A | Sensor, Automatic Light Control |
| 89129 | Bracket, Conlight Scanner |
| 89221B | Computer, Body |
| 89245B | Sensor, Steering |
| 89279A | Cover, Computer |
| 89280 | Sensor Assy, Clutch Pedal Stroke |
| 89420M | Sensor Assy, Air Pressure |
| 89424B | Switch, Inlet Air Temperature |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89425A | Sensor, Exhaust Gas Temperature, NO.2 |
| 89425B | Sensor, Exhaust Gas Temperature, NO.3 |
| 89425C | Sensor, Exhaust Gas Temperature, NO.4 |
| 89437 | Cover, Sensor |
| 89437B | Cover, Sensor |
| 89439 | Bracket, Sensor |
| 89439D | Bracket, Sensor, NO.1 |
| 89458D | Sensor, Fuel Pressure |
| 89458G | Sensor, Fuel Pressure, NO.2 |
| 89463A | Sensor, Nitrogen Oxides |
| 89463B | Relay, Nitrogen Oxides |
| 89481B | Sensor, Differential Pressure |
| 89530C | Computer Assy, Transmission Control |
| 89537A | Cover, Computer |
| 89539E | Bracket, Computer |
| 89539Q | Bracket, Computer |
| 89880 | Computer Assy, Electric Vehicle Control |
| G9271C | Cover, Converter |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
