Toyota Dyna/Toyoace
1977-08 → 1984-08 · chassis HU26,30,40,50,JU20,RU2#,3#,WU26,40,50 · catalogue 752120 · Japan
Discontinued model
Data version 1985-03
Switch & Relay & Computer
90 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 27679 | Bracket, Exhaust Brake(FOR SOLENOID) |
| 27690 | Solenoid Assy, W/Bracket(FOR EXHAUST BRAKE) |
| 28300 | Relay Assy, Starter |
| 28490 | Relay Assy, Exhaust Brake |
| 28491 | Computer, Exhaust Brake |
| 28521 | Timer, Preheating |
| 28550 | Controller Assy, Glow Plug |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 28611 | Cover, Glow Plug Relay |
| 28621 | Resistor, Glow Plug |
| 28624 | Plate, Current Sensor |
| 28631 | Sensor, Glow Plug Current |
| 74702 | Bracket Sub-assy, Work Lamp Switch |
| 81402 | Socket Sub-assy, Inspection Lamp, NO.1 |
| 81402A | Bracket, Inspection Lamp Socket |
| 81980 | Flasher Assy, Turn Signal |
| 82600F | Fuse, Fuse Block |
| 82616 | Puller, Fuse |
| 83320 | Gage Assy, Fuel Sender |
| 83320A | Gage Assy, Fuel Sender (FOR FUEL SUB-TANK) |
| 83361 | Gasket, Fuel Sender Gage |
| 83390 | Switch Assy, Vacuum Warning |
| 83391 | Switch, Vacuum |
| 83399 | Bracket, Vacuum Switch |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 83651 | Clamp, Fusee |
| 84095 | Bracket Sub-assy, Hand Brake Signal Switch |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84113A | Bracket, Switch, NO.1 |
| 84150 | Switch Assy, Fog Lamp |
| 84150A | Bolt, Fog Lamp Switch |
| 84151 | Knob, Fog Lamp Switch |
| 84210 | Switch Assy, Back-up Lamp |
| 84210T | Sensor Assy, Shift Point |
| 84231 | Switch Assy, Courtesy Lamp (FOR PARKING BRAKE) |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84260 | Switch Assy, Deck Lamp |
| 84262 | Switch Assy, Exhaust Brake |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84335 | Switch Assy, Parking Lamp |
| 84340 | Switch Assy, Stop Lamp |
| 84450 | Switch Assy, Ignition OR Starter |
| 84510A | Switch Assy, Starter (FOR TILT CAB) |
| 84540B | Switch Assy, Neutral Start (FOR TILT CAB) |
| 84540C | Switch Assy, Neutral (FOR EXHAUST BRAKE) |
| 84640 | Switch Assy, Exhaust Brake |
| 84641 | Switch, Exhaust Brake, NO.1 |
| 84650 | Switch Assy, Windshield Wiper |
| 84730 | Switch Assy, Heater Blower |
| 84730A | Nut, Heater Blower Switch |
| 84731 | Knob, Heater Blower Switch |
| 84731R | Knob, Rear Heater Blower Switch |
| 84732A | Switch, Rear Heater Blower |
| 84732C | Nut, Rear Heater Blower Switch |
| 84734R | Plate, Rear Heater Blower Switch Caution |
| 84750A | Switch Assy, Seat |
| 84810 | Switch Assy, Power Window Regulator |
| 84957A | Support, Power Window Regulator Switch |
| 85336 | Switch Assy, Reserve Tank Level Warning |
| 85500 | Lighter Assy, Cigarette |
| 85540 | Resistance Assy, Cigarette Lighter |
| 85910G | Relay, Heater Pump |
| 85916 | Relay, Light Control |
| 85939 | Relay, Power Window |
| 85940 | Relay Assy, Windshield Wiper |
| 85959A | Holder, Relay |
| 85999 | Bracket, Combination Relay |
| 85999A | Bracket, Relay, NO.2 |
| 85999C | Bracket, Relay, NO.3 |
| 86530 | Relay Assy, Horn |
| 86650 | Buzzer Assy, Vacuum Indicator |
| 86651 | Buzzer Assy, Back |
| 86690 | Buzzer Assy, Speed Indicator |
| 87295 | Switch Assy, Temperature Control |
| 87481 | Switch Assy, Heater |
| 89371 | Relay, Lamp Failure Indicator |
| 89411B | Sensor, Speed |
| 89427 | Switch, Temperature Detect |
| 89428 | Switch, Temperature Detect, NO.2 |
| 89429 | Sensor, Oil Temperature |
| 89491 | Sensor, Engine Oil Level |
| 89491A | Gasket, Engine Oil Level Sensor |
| 89492 | Sensor, Electrolyte Level |
| 89550 | Computer Assy, Emission Control |
| 89590 | Computer Assy, Condition Indicator |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
