Toyota Dyna/Toyoace
1984-09 → 1987-08 · chassis YU6#,70,80,WU75,9# · catalogue 752130 · Japan
Discontinued model
Data version 1988-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 17700 — Cleaner Assy, Air | ||||
| 17700-58110 |
Cleaner Assy, Air
1984-09 → 1987-08
ended
|
1W WU75,9# | ¥41,600 | |
| 17700-73080 |
Cleaner Assy, Air
1984-09 → 1986-04
ended
|
3Y YU6#,70 | ¥51,700 | |
| 17700-73081 |
Cleaner Assy, Air
1986-04 → 1987-08
ended
|
3Y YU6#,70 | ¥51,800 | |
| 17700-73100 |
Cleaner Assy, Air
1984-09 → 1986-04
ended
|
3YP YU60,80 | ¥31,500 | |
| 17700-73101 |
Cleaner Assy, Air
1986-04 → 1987-08
ended
|
3YP YU60,80 | ¥31,400 | |
| 17700A — Nut, Wing(FOR AIR CLEANER) | ||||
| 90099-05187 |
Nut, Wing(FOR AIR CLEANER)
1984-09 → 1986-04
ended
|
3Y# YU6#,70,80 | — | |
| 90175-06003 |
Nut, Wing(FOR AIR CLEANER)
1986-04 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 90175-08008 |
Nut, Wing(FOR AIR CLEANER)
1984-09 → 1987-08
ended
|
1W WU75,9# | — | |
| 17701 — Case Sub-assy, Air Cleaner | ||||
| 17701-56130 |
Case Sub-assy, Air Cleaner
1984-09 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 17701-58040 |
Case Sub-assy, Air Cleaner
1984-09 → 1987-08
ended
|
1W WU75,9# | — | |
| 17708 — Baffle Sub-assy, Air Cleaner | ||||
| 17708-56010 |
Baffle Sub-assy, Air Cleaner
1986-04 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 17744 — Cup, Precleaner | ||||
| 17744-56010 |
Cup, Precleaner
1984-09 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 17771 — Bracket, Air Cleaner Inlet Duct | ||||
| 17771-56020 |
Bracket, Air Cleaner Inlet Duct
1984-09 → 1987-08
ended
|
3Y# YU60,70,80 | ¥1,800 | |
| 17801 — Element Sub-assy, Air Cleaner Filter | ||||
| 17801-56030 |
Element Sub-assy, Air Cleaner Filter
1984-09 → 1986-04
ended
|
3Y# YU6#,70,80 | ¥3,890 | |
| 17801-56031 |
Element Sub-assy, Air Cleaner Filter
1986-04 → 1987-08
ended
|
3Y# YU6#,70,80 | ¥3,890 | |
| 17801-68020 |
Element Sub-assy, Air Cleaner Filter
1984-09 → 1987-08
ended
|
1W WU75,9# | ¥3,990 | |
| 17841 — Gasket, Filter Element | ||||
| 17841-56030 |
Gasket, Filter Element
1984-09 → 1986-04
ended
|
3Y# YU6#,70,80 | — | |
| 17841-56031 |
Gasket, Filter Element
1986-04 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 17841-68010 |
Gasket, Filter Element
1984-09 → 1987-08
ended
|
1W WU75,9# | ¥0 | |
| 17845 — Gasket, Air Cleaner Cap | ||||
| 17845-56050 |
Gasket, Air Cleaner Cap
1984-09 → 1987-08
ended
|
3Y# YU6#,70,80 | — | |
| 17845-68020 |
Gasket, Air Cleaner Cap
1984-09 → 1987-08
ended
|
1W WU75,9# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
