Toyota Dyna/Toyoace Quick

1986-01 → 1995-05 · chassis BU60 · catalogue 761110 · Japan

Discontinued model Data version 1995-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Heating & Air Conditioning - Control & Air Duct

30 part groups · 2 illustrations

Illustrations

Figure MEG856C MEG856C 1986-01 → — Figure MEG857D MEG857D 1986-01 → —

Part groups

PNCDescription
55903 Lever Sub-assy, Heater Control
55905A Knob, Heater Control
55906 Cable Sub-assy, Heater Control
55906A Cable Sub-assy, Defroster Damper Control
55907A Cable Sub-assy, Water Valve Control
55908A Cable Sub-assy, Air Inlet Damper Control
55909A Cable Sub-assy, Airmix Damper Control
55910 Control Assy, Heater OR Boost Ventilator
55939 Ornament, Heater Control
87210 Damper Assy, Air
87211 Duct, Air, NO.1
87211A Duct, Air, NO.2
87211B Duct, Air, NO.3
87214 Duct, Air, Side NO.1 RH
87214A Duct, Air, Side NO.2 RH
87214B Duct, Air, Side NO.3 RH
87215 Duct, Air, Side NO.1 LH
87226 Adapter, Air Duct
87231 Hose, Heater Defroster, RH
87231A Duct, Heater Defroster, Side NO.1 RH
87232 Hose, Heater Defroster, LH
87232A Duct, Heater Defroster, Side NO.1 LH
87233 Hose, Heater Defroster, Center
87234 Adapter, Defroster Hose
87281 Bracket, Air Duct
87284 Resistor Sub-assy, Variable
88505 Duct Sub-assy,Air Conditioner
88539F Hose, Drain
88539P Grommet(FOR DRAIN HOSE)
88630K Relay Assy
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
