Toyota Dyna/Toyoace
1999-05 → 2011-06 · chassis BU4##,BZU410,XZU3##,4## · catalogue 771130 · Japan
Discontinued model
Data version 2012-01
Suspension Crossmember & Under Cover
31 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 51407A | Cover Sub-assy, Engine Under, NO.3 |
| 51407B | Bracket Sub-assy, Engine Under Cover |
| 51436B | Bracket, Engine Side Cover, NO.1 RH |
| 51437A | Bracket, Engine Side Cover, NO.1 LH |
| 51439A | Bracket, Engine Side Cover, NO.2 LH |
| 51441 | Cover, Engine Under, NO.1 |
| 51441D | Cover, Engine Under |
| 51442 | Cover, Engine Under, NO.2 |
| 51442C | Cover, Engine Under, LH |
| 51442E | Cover, Engine Under, NO.2 |
| 51445D | Bracket, Engine Under Cover, RH |
| 51446C | Bracket, Engine Under Cover, LH |
| 51448B | Shutter, Engine Rear Side |
| 51454C | Silencer, Engine Under Cover, Rear |
| 51463C | Silencer, Engine Under Cover, RH |
| 51464 | Silencer, Transmission Under, LH |
| 51464A | Silencer, Engine Under Cover, LH |
| 51470 | Cover Assy, Transmission Under |
| 51473A | Cover Sub-assy, Engine Side, RH |
| 51474 | Cover Sub-assy, Engine Side, LH |
| 51475 | Silencer, Engine Under Cover, NO.5 |
| 51477A | Silencer, Engine Under Cover, RH |
| 51478 | Plate, Engine Side Under Cover, Upper LH |
| 51478A | Silencer, Engine Under Cover, LH |
| 51490 | Shutter Assy, Engine Rear Side, LH |
| 51961C | Hook, Front |
| 51961D | Spacer, Front Hook |
| 51962 | Hook, NO.2 |
| 51963B | Hook, Transport, Front RH |
| 51964B | Hook, Transport, Front LH |
| 51965A | Retainer, Front Hook |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
