Toyota Dyna/Toyoace
1999-05 → 2011-06 · chassis BU4##,BZU410,XZU3##,4## · catalogue 771130 · Japan
Discontinued model
Data version 2012-01
Roof Panel & Back Panel
53 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 53709D | Bracket Sub-assy, Air Cleaner Inlet Seal |
| 53764A | Bracket, Air Cleaner Inlet, NO.1 |
| 53765B | Bracket, Air Cleaner Inlet, NO.2 |
| 53773B | Bracket, Air Cleaner Inlet, NO.2 |
| 58993C | Bracket, Console Box Mounting, Rear |
| 59189A | Cover, Noise Shutter Side |
| 59190A | Guard Assy, Noise Shutter |
| 59195B | Insulator, Noise Shutter |
| 59196C | Insulator, Noise Shutter, LH |
| 63101 | Panel Sub-assy, Roof |
| 63103A | Reinforcement Sub-assy, Roof Panel |
| 63141G | Reinforcement, Roof Panel, NO.1 |
| 63142D | Reinforcement Sub-assy, Roof Panel, Rear |
| 63151B | Seal, Roof Panel Reinforcement |
| 63185A | Bracket, Roof Rack, Front RH |
| 63186A | Bracket, Roof Rack, Front LH |
| 63209 | Panel Sub-assy, Roof Wind Deflector |
| 63212B | Panel, Roof Wind Deflector |
| 63213B | Panel, Sliding Roof, Inner |
| 63223B | Bracket, Roof Wind Deflector, RH |
| 63224B | Bracket, Roof Wind Deflector, LH |
| 63230B | Panel Assy, Roof Wind Deflector |
| 63231 | Bracket, Room Lamp |
| 63273R | Packing, Roof Window Defrector |
| 63332D | Pad, Sun Roof Headlining |
| 63358D | Bracket, Roof Silencer, Rear |
| 63403 | Deck Sub-assy, Roof Rack |
| 63467 | Bracket, Roof Rack, Rear RH |
| 63468 | Bracket, Roof Rack, Rear LH |
| 63495A | Cover, Roof Rack Leg, Center |
| 63701A | Bracket Sub-assy, Roof Air Deflector, Front |
| 63703 | Bar Sub-assy, Roof Air Deflector, NO.1 |
| 63765A | Bracket, Roof Air Deflector, RH |
| 63766A | Bracket, Roof Air Deflector, LH |
| 63776 | Bar, Roof Air Deflector, NO.2 |
| 63781 | Stay, Roof Air Deflector |
| 64111A | Panel, Back |
| 64115B | Reinforcement, Back Panel |
| 64117A | Reinforcement, Cab Back, Lower |
| 64118C | Reinforcement, Cab Back Side, RH |
| 64119B | Reinforcement, Cab Back Side, LH |
| 64121F | Baffle, Dust Rear Body, RH |
| 64122A | Baffle, Dust Rear Body |
| 64125E | Extension, Back Corner Panel, RH |
| 64125F | Bracket, Upper Back Panel |
| 64126A | Bracket, Upper Back Panel, LH |
| 64126E | Extension, Back Corner Panel, LH |
| 64145D | Bracket, Rear Seatback Set |
| 64277E | Bracket, Back Panel Trim, Lower |
| 64811 | Glass, Back Window |
| 64831 | Weatherstrip, Back Window Glass |
| 64832 | Key, Back Window Weatherstrip |
| 86245A | Bracket, Voltage Converter |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
