Toyota Land Cruiser S/T,H/T
1980-08 → 1984-10 · chassis BJ4# · catalogue 781110 · Japan
Discontinued model
Data version 1985-04
Wiring & Clamp
24 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 82001 | Cable, Bond, NO.1 |
| 82002 | Cable, Battery TO Magnet Switch |
| 82002A | Cable, Magnet Switch TO Winch |
| 82002B | Cable, Winch TO Ground |
| 82024 | Wire Sub-assy, Fog Lamp Feed |
| 82051 | Harness Assy, Fuel Control |
| 82210 | Harness Assy, Wiring Cowl TO Headlamp, NO.1 |
| 82210C | Fusible Link |
| 82211A | Wire, Rear Heater |
| 82215 | Wire, Parking Brake Lamp Switch |
| 82220 | Harness Assy, Wiring Cowl |
| 82291 | Wiring, TO Solenoid |
| 82310 | Wiring Assy, TO Back UP Lamp Switch |
| 82345 | Diode |
| 82351A | Wire, Courtesy Lamp Switch (FOR FRONT OR REAR DOOR) |
| 82370 | Wire Assy, Wiper Switch TO Wiper |
| 82374 | Wire, Washer |
| 82412 | Wire, Fuel Gage |
| 82420 | Wiring Assy, Chassis |
| 82470 | Wire Assy, License Lamp Feed |
| 82510 | Wiring Assy, Roof |
| 82670 | Block Assy, Junction, NO.1 |
| 82672 | Cover, Junktion Block |
| 82823 | Cap, Terminal, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
