Toyota Land Cruiser Prado

2002-09 → 2009-08 · chassis GRJ12#,KDJ12#,RZJ12#,TRJ12#,VZJ12# · catalogue 781150 · Japan

Supported model Data version 2010-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate

30 part groups · 3 illustrations

Illustrations

Figure 746109 746109 2002-09 → — Figure 741143M 741143M 2002-09 → — Figure 741475N 741475N 2002-09 → —

Part groups

PNCDescription
11285F Label, Coolant System Caution
11286B Plate, Engine Specification
11289B Label, Spark Plug Notice
11293D Label, Engine Caution
11296C Label, Engine Service Information
11297C Label, Engine Service Information, NO.2
17791A Label, Maintenance Information
36369 Label, Transfer Information
41991A Plate, Caution
47288 Label, Brake Fluid Notice
48969 Label, Jack UP Caution
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515A Plate, Theft Warning
74529 Plate, Child Proof OR Child Protector Lock Caution
74542 Plate, Rear Window Mark
74543C Label, Rear Seat Information
74543J Label, Rear Seat Caution
74544D Plate, Tire Carrier Caution
74552 Plate, Safety Caution
74559A Plate, Fuel Caution
74561A Label, Fuel Consumption Information
74562B Label, Emission Information
74579A Label, Unleaded Fuel Information
74751 Label, Tire Pressure Information
82685 Plate, Caution
87511A Plate, Seat Heater Caution
87529B Label, A/C Filter Information
88723E Label, Cooler Service Caution
88723H Label, Cooler Service Caution
89176A Label, Airbag Deployment Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
