Toyota Land Cruiser
2014-08 → present · chassis GRJ7# · catalogue 781170 · Japan
Supported model
Data version 2023-11
Air Cleaner
21 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 17360E | Tube Assy, Air, NO.1 |
| 17360F | Tube Assy, Air, NO.2 |
| 17700 | Cleaner Assy, Air |
| 17705 | Cap Sub-assy, Air Cleaner |
| 17743 | Valve, Dust Relief |
| 17750 | Cover Assy, Air Cleaner Inlet, Seal |
| 17751 | Inlet, Air Cleaner, NO.1 |
| 17771A | Bracket, Air Cleaner |
| 17801 | Element Sub-assy, Air Cleaner Filter |
| 17861 | Connector, Intake Air |
| 17881 | Hose, Air Cleaner, NO.1 |
| 17881A | Clamp(FOR AIR CLEANER HOSE, NO.1) |
| 17881C | Clamp(FOR AIR CLEANER HOSE, NO.1) |
| 17882 | Hose, Air Cleaner, NO.2 |
| 17882A | Clamp(FOR AIR CLEANER HOSE, NO.2) |
| 17894B | Clamp, Hose(FOR INTAKE AIR RESONATOR, NO.2) |
| 17940D | Intercooler Assy |
| 17945 | Bracket, Intercooler Support |
| 17946 | Bracket, Intercooler Support, NO.2 |
| 22204 | Meter Sub-assy, Intake Air Flow |
| 22204A | Ring, O(FOR INTAKE AIR FLOW METER) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
