Toyota Land Cruiser Van
1980-08 → 1987-08 · chassis BJ6#,FJ6#,HJ6# · catalogue 791120 · Japan
Discontinued model
Data version 1988-01
Carburetor Assembly
20 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 04211 | Carburetor Kit |
| 04212 | Gasket Kit, Carburetor |
| 21100 | Carburetor Assy |
| 21673 | Cap, Idle Limit |
| 21911 | Gasket, Carburetor |
| 21912 | Insulator, Carburetor Heat |
| 26300 | Governor Assy |
| 26300B | Governor Assy, W/NO.1 Pulley Bracket |
| 26300C | Bracket, Governor, NO.2 |
| 26300D | Belt, Governor |
| 26300E | Valve Assy, Butterfly |
| 26300F | Rod Assy, Connecting |
| 26400 | Solenoid Assy, Governor Control |
| 26400A | Cable Assy, Governor Control |
| 26400B | Bracket, Solenoid |
| 26400C | Support, Governor Control Cable, NO.1 |
| 26400D | Support, Governor Control Cable, NO.2 |
| 26400E | Support, Governor Spring |
| 26400F | End, Governor Control Cable |
| 26400G | Ball, Governor Control Cable |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
