Toyota Land Cruiser Van
1987-08 → 1990-01 · chassis FJ6#,HJ6# · catalogue 791130 · Japan
Discontinued model
Data version 1990-06
Power Steering Tube
14 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 44348A | Hose, Oil Reservoir TO Pump, NO.1 |
| 44348B | Clamp(FOR OIL RESERVOIR TO PUMP HOSE) |
| 44350 | Pulley Assy, Power Steering Idle |
| 44402A | Hose, Power Steering Oil Cooler Inlet |
| 44402B | Hose, Power Steering Oil Cooler Outlet |
| 44402C | Clamp, Power Steering Oil Cooler Inlet Hose |
| 44411 | Hose, Pressure Feed |
| 44411C | Bolt, Union(FOR PRESSURE FEED HOSE) |
| 44411D | Gasket(FOR PRESSURE FEED HOSE) |
| 44416 | Tube, Return(FOR STEERING GEAR OUTLET) |
| 44420 | Cooler Assy, Oil |
| 44443 | Bracket, Pump |
| 44446 | Strut, Adjusting |
| 44447A | Bracket, Hose Support, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
