Toyota Land Cruiser
1998-01 → 2007-08 · chassis HDJ101,UZJ100 · catalogue 791150 · Japan
Discontinued model
Data version 2008-04
Navigation & Front Monitor Display
20 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 83240 | Case Assy, Multi Information Display |
| 83244A | Computer, Multi Information Display |
| 83253A | Glass, Accessory Meter |
| 86010 | Tuner Assy, Television |
| 86029A | Bracket Set, Television, NO.1 |
| 86101H | Cord Sub-assy, Antenna |
| 86111 | Multi-display |
| 86112 | Computer, Multi-display (COMPUTER CRT DISPLAY) |
| 86271 | Disc, Disc Player |
| 86274D | Bracket, Disc Player |
| 86274F | Bracket, Disc Player, NO.2 |
| 86841 | Computer, Navigation |
| 86842 | Wire, Navigation, NO.1 |
| 86843 | Cover, Navigation Computer |
| 86860 | Antenna Assy, Navigation |
| 86915 | Transceiver, Optical Beacon |
| 86920 | Antenna Assy, Traffic Information |
| 86923 | Detector, Traffic Information |
| 86931 | Computer, Traffic Information |
| 86932 | Wire, Traffic Information |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
