Toyota Land Cruiser
2007-09 → present · chassis UZJ200,URJ202 · catalogue 791160 · Japan
Supported model
Data version 2018-08
Navigation & Front Monitor Display
14 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 86110B | Multi-display Assy |
| 86117 | Bracket, Multi-display Controller, A |
| 86211J | Bracket, Radio Receiver, NO.1 |
| 86212C | Bracket, Radio Receiver, NO.2 |
| 86250E | Microphone Assy, Amplifier |
| 86271 | Disc, Disc Player |
| 86271L | Hard Disc |
| 86273B | Adapter, Disc Player |
| 86730A | Microphone Assy, Telephone |
| 86804A | Sub-assy, Navigation Computer |
| 86842 | Wire, Navigation, NO.1 |
| 86860 | Antenna Assy, Navigation |
| 86915 | Transceiver, Optical Beacon |
| 86994A | Wire, Toll Collection Antenna |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
