Toyota Land Cruiser
2007-09 → present · chassis UZJ200,URJ202 · catalogue 791160 · Japan
Supported model
Data version 2018-08
Mirror
19 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 81880D | Bulb, Outer Mirror Lamp Assy |
| 87810 | Mirror Assy, Inner Rear View |
| 87834 | Cover, Inner Rear View Mirror Stay Holder |
| 87907 | Mirror Sub-assy, Outer Under View |
| 87908 | Actuator Assy, Outer Mirror, RH |
| 87909 | Actuator Assy, Outer Mirror, LH |
| 87910 | Mirror Assy, Outer Rear View, RH |
| 87915A | Cover, Outer Mirror, RH |
| 87930 | Device Assy, Front Fender Side View, LH |
| 87931 | Outer Mirror, RH |
| 87939 | Cover, Outer Mirror Hole, RH |
| 87940 | Mirror Assy, Outer Rear View, LH |
| 87945B | Cover, Outer Mirror, LH |
| 87946 | Retractor, Outer Mirror, RH |
| 87948 | Cover, Outer Mirror Hole, LH |
| 87950 | Mirror Assy, Outer Under Rear View |
| 87961 | Mirror Outer, LH |
| 87966 | Retractor, Outer Mirror, LH |
| 87973 | Cover, Outer Under RR View Mirror |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
