Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04438H — Boot Kit, Front Drive Shaft, IN & Outboard, LH | ||||
| 04427-60160 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥6,700 | |
| 04427-60170 note |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥6,700 | |
| 04438J — Boot Kit, Front Drive Shaft Inboard Joint, LH | ||||
| 04437-60110 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥4,150 | |
| 04437-60120 note |
Boot Kit, Front Drive Shaft Inboard Joint, LH
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 41336E — Cover, Front Drive Shaft Dust, LH | ||||
| 41336-60010 |
Cover, Front Drive Shaft Dust, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥680 | |
| 43404 — Joint Set, Front Axle Inboard, LH | ||||
| 43403-60050 |
Joint Set, Front Axle Inboard, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥18,900 | |
| 43403-60060 note |
Joint Set, Front Axle Inboard, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥18,900 | |
| 43412B — Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH) | ||||
| 43425-60030 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥60 | |
| 43420 — Shaft Assy, Front Drive, LH | ||||
| 43420-60230 |
Shaft Assy, Front Drive, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥46,900 | |
| 43420-60240 note |
Shaft Assy, Front Drive, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥46,900 | |
| 43420G — Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH) | ||||
| 90521-37010 note |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥90 | |
| 90521-39002 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥90 | |
| 43420H — Oil Seal, Front Drive Shaft, LH | ||||
| 90311-47040 |
Oil Seal, Front Drive Shaft, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥610 | |
| 43447E — Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH) | ||||
| 42345-60130 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥260 | |
| 43447F — Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH) | ||||
| 42345-60260 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥570 | |
| 43448F — Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH) | ||||
| 42345-60130 |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥260 | |
| 43448G — Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH) | ||||
| 42345-60250 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥550 | |
| 43502K — Seal, Dust (FOR FRONT AXLE HUB LH) | ||||
| 90304-94001 |
Seal, Dust (FOR FRONT AXLE HUB LH)
2021-12 → 2024-11
ended
|
VJA310 | ¥810 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
