Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 45020C — Actuator Assy, Steering Lock(W/ECU) | ||||
| 45020-60880 |
Actuator Assy, Steering Lock(W/ECU)
2021-12 → 2024-11
ended
|
VJA310 | ¥14,300 | |
| 45024 — Cover Sub-assy, Steering Column, Lower | ||||
| 45024-60060-C0 note |
Cover Sub-assy, Steering Column, Lower
2021-12 → 2024-11
ended
|
VJA310 | ¥2,490 | |
| 45025D — Cover Sub-assy, Steering Column Hole, NO.1 | ||||
| 45025-60290 |
Cover Sub-assy, Steering Column Hole, NO.1
2021-12 → 2024-11
ended
|
VJA310 | ¥3,360 | |
| 45203 — Shaft Sub-assy, Steering Intermediate, NO.2 | ||||
| 45203-60280 |
Shaft Sub-assy, Steering Intermediate, NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥10,800 | |
| 45220 — Shaft Assy, Steering Intermediate | ||||
| 45220-60390 |
Shaft Assy, Steering Intermediate
2021-12 → 2024-11
ended
|
VJA310 | ¥11,700 | |
| 45221 — Shaft, Steering Intermediate | ||||
| 45221-60270 |
Shaft, Steering Intermediate
2021-12 → 2024-11
ended
|
VJA310 | ¥9,300 | |
| 45238 — Clamp, Bolt(FOR STEERING FLEXIBLE COUPLING) | ||||
| 45238-11010 |
Clamp, Bolt(FOR STEERING FLEXIBLE COUPLING)
2021-12 → 2024-11
ended
|
VJA310 | ¥70 | |
| 45250 — Column Assy, Steering | ||||
| 45250-48430 |
Column Assy, Steering
2021-12 → 2024-11
ended
|
VJA310 | ¥101,000 | |
| 45286B — Cover, Steering Column, Upr | ||||
| 45286-78030-C0 note |
Cover, Steering Column, Upr
2021-12 → 2024-11
ended
|
VJA310 | ¥1,350 | |
| 45897 — Bolt, Steering Lock Set | ||||
| 45897-12020 |
Bolt, Steering Lock Set
2021-12 → 2024-11
ended
|
VJA310 | ¥210 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
