Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 48960 — Valve Assy, Height Control, NO.2 | ||||
| 48960-60020 |
Valve Assy, Height Control, NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥53,600 | |
| 489D4 — Bracket, Height Control Valve, LH | ||||
| 489D4-60020 |
Bracket, Height Control Valve, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥1,220 | |
| 49020 — Valve Assy, Front Suspension Control, LH | ||||
| 490B0-60020 |
Valve Assy, Front Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥46,400 | |
| 49040A — Accumulator Assy, Front Suspension Control, LH | ||||
| 49040-60050 |
Accumulator Assy, Front Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥94,600 | |
| 49050 — Accumulator Assy, Rear Suspension Control, LH | ||||
| 49050-60060 |
Accumulator Assy, Rear Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥94,600 | |
| 49070 — Valve Assy, Rear Suspension Control, LH | ||||
| 490D0-60010 |
Valve Assy, Rear Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥58,100 | |
| 49114A — Bracket, Front Suspension Control, LH | ||||
| 49114-60010 |
Bracket, Front Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥2,100 | |
| 49124 — Bracket, Rear Suspension Control, LH | ||||
| 49124-60010 |
Bracket, Rear Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥2,560 | |
| 49141D — Accumulator, Front Suspension Control, LH | ||||
| 49141-60040 |
Accumulator, Front Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥10,300 | |
| 49151B — Accumulator, Rear Suspension Control, LH | ||||
| 49151-60040 |
Accumulator, Rear Suspension Control, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥10,300 | |
| 49177 — Cap, Bleeder Plug Suspension Control | ||||
| 31478-60020 |
Cap, Bleeder Plug Suspension Control
2021-12 → 2024-11
ended
|
VJA310 | ¥30 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
