Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82191 — Wire, Front Seat, RH | ||||
| 82191-60L90 |
Wire, Front Seat, RH
2021-12 → 2024-11
ended
|
VJA310 | ¥9,900 | |
| 82192 — Wire, Front Seat, LH | ||||
| 82192-60F40 note |
Wire, Front Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥7,200 | |
| 82192-60F60 |
Wire, Front Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥8,500 | |
| 82192-60K60 note |
Wire, Front Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥10,100 | |
| 82193 — Wire, Rear Seat, RH | ||||
| 82193-60420 note |
Wire, Rear Seat, RH
2021-12 → 2024-11
ended
|
VJA310 | ¥10,100 | |
| 82193-60430 note |
Wire, Rear Seat, RH
2021-12 → 2024-11
ended
|
VJA310 | ¥4,640 | |
| 82193-60460 |
Wire, Rear Seat, RH
2021-12 → 2024-11
ended
|
VJA310 | ¥7,700 | |
| 82194 — Wire, Rear Seat, LH | ||||
| 82194-60280 note |
Wire, Rear Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 82194-60320 |
Wire, Rear Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥6,500 | |
| 82194-60340 note |
Wire, Rear Seat, LH
2021-12 → 2024-11
ended
|
VJA310 | ¥10,100 | |
| 8219A — Wire, Front Seat, RH NO.2 | ||||
| 8219A-60180 |
Wire, Front Seat, RH NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥5,100 | |
| 8219B — Wire, Front Seat, LH NO.2 | ||||
| 8219B-60120 note |
Wire, Front Seat, LH NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥4,130 | |
| 8219B-60190 |
Wire, Front Seat, LH NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥4,640 | |
| 8219B-60210 note |
Wire, Front Seat, LH NO.2
2021-12 → 2024-11
ended
|
VJA310 | ¥7,700 | |
| 8219C — Wire, Seat Audio | ||||
| 8219C-60030 note |
Wire, Seat Audio
2021-12 → 2024-11
ended
|
VJA310 | ¥2,680 | |
| 8219C-60030 note |
Wire, Seat Audio
2021-12 → 2024-11
ended
|
VJA310 | ¥2,680 | |
| 8219C-60040 note |
Wire, Seat Audio
2021-12 → 2024-11
ended
|
VJA310 | ¥2,680 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
