Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87201N — Duct Sub-assy, Air | ||||
| 55848-50010 |
Duct Sub-assy, Air
2021-12 → 2024-11
ended
|
VJA310 | ¥190 | |
| 88051A — Generator Sub-assy,Ion | ||||
| 88051-48010 |
Generator Sub-assy,Ion
2021-12 → 2024-11
ended
|
VJA310 | ¥16,200 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
