Toyota Lexus LX600
2021-12 → present · chassis VJA310 · catalogue 792170 · Japan
Supported model
Data version 2022-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 57423H — Clamp, Heater Cover | ||||
| 57423-26010 |
Clamp, Heater Cover
2021-12 → 2024-11
ended
|
VJA310 | ¥160 | |
| 87209 — Hose Sub-assy, Water | ||||
| 87209-60L80 |
Hose Sub-assy, Water
2021-12 → 2024-11
ended
|
VJA310 | ¥8,700 | |
| 87237 — Cover, Heater Piping | ||||
| 87237-60020 |
Cover, Heater Piping
2021-12 → 2024-11
ended
|
VJA310 | ¥2,370 | |
| 87245D — Hose, Heater Water, Inlet D | ||||
| 87242-60050 |
Hose, Heater Water, Inlet D
2021-12 → 2024-11
ended
|
VJA310 | ¥1,720 | |
| 87246D — Hose, Heater Water, Outlet D | ||||
| 87242-60060 |
Hose, Heater Water, Outlet D
2021-12 → 2024-11
ended
|
VJA310 | ¥1,950 | |
| 87248X — Pipe, Heater Water | ||||
| 87248-60C60 |
Pipe, Heater Water
2021-12 → 2024-11
ended
|
VJA310 | ¥4,620 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
