Toyota Coaster
1982-05 → 1993-01 · chassis RB2#,BB2#,3#,HB3#,HZB3#,HDB20,3# · catalogue 811120 · Japan
Discontinued model
Data version 1993-12
Switch & Relay & Computer
126 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 27690 | Solenoid Assy, W/Bracket(FOR EXHAUST BRAKE) |
| 27790 | Relay Assy, Charge Lamp |
| 28300 | Relay Assy, Starter |
| 28491 | Computer, Exhaust Brake |
| 28521 | Timer, Preheating |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 28611 | Cover, Glow Plug Relay |
| 28621 | Resistor, Glow Plug |
| 28624 | Plate, Current Sensor |
| 28625 | Plate, Glow Plug Resistor |
| 28631 | Sensor, Glow Plug Current |
| 81980 | Flasher Assy, Turn Signal |
| 82600F | Fuse, Fuse Block |
| 82611 | Cover, Fuse Block |
| 82630 | Holder Assy, Fuse |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 82650A | Breaker Assy, Wiring Circuit, NO.2 |
| 82650B | Breaker Assy, Wiring Circuit, NO.3 |
| 82655 | Bracket, Curcuit Breaker |
| 82661 | Cover, Relay Block, NO.1 |
| 82829 | Cover, Relay |
| 83320 | Gage Assy, Fuel Sender |
| 83320A | Gage Assy, Fuel Sender (FOR FUEL SUB-TANK) |
| 83330 | Switch Assy, Fuel Level |
| 83360A | Relay Assy, Fuel Level |
| 83361 | Gasket, Fuel Sender Gage |
| 83361A | Gasket, Fuel Level Switch |
| 83381A | Switch, Pressure |
| 83381B | Hose, Vacuum |
| 83389A | Bracket, Pressure Switch |
| 83390 | Switch Assy, Vacuum Warning |
| 83391 | Switch, Vacuum |
| 83399 | Bracket, Vacuum Switch |
| 83420 | Gage Assy, Water Temperature Sender |
| 83481 | Sensor, Inner Ambient Temperature |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 83651 | Clamp, Fusee |
| 83970B | Buzzer Assy, Reverse Warning |
| 84095 | Bracket Sub-assy, Hand Brake Signal Switch |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84118 | Knob, Light Control Rheostat |
| 84119 | Rheostat, Light Control |
| 84160 | Switch Assy, Room Lamp |
| 84210 | Switch Assy, Back-up Lamp |
| 84225A | Switch, Shift Position |
| 84230E | Switch Assy, Courtesy Lamp (FOR CENTER DOOR INDICATOR) |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84233B | Cushion, Courtesy Switch (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84235 | Switch Assy, Courtesy Lamp(FOR BACK DOOR) |
| 84235B | Cushion, Courtesy Switch(FOR BACK DOOR) |
| 84261B | Junction, Slide Door Control,Male |
| 84262B | Junction, Slide Door Control, Female |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84335 | Switch Assy, Parking Lamp |
| 84340 | Switch Assy, Stop Lamp |
| 84450 | Switch Assy, Ignition OR Starter |
| 84455 | Switch, Warm UP |
| 84455B | Bulb (FOR WARM UP SWITCH) |
| 84461 | Switch, Level Warning |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84640 | Switch Assy, Exhaust Brake |
| 84650 | Switch Assy, Windshield Wiper |
| 84653A | Switch, Rear Wiper |
| 84680 | Switch Assy, Exhaust Brake Main |
| 84730 | Switch Assy, Heater Blower |
| 84730B | Bulb, Heater Blower Switch |
| 84732A | Switch, Rear Heater Blower |
| 84790 | Switch Assy, Rear Window Defogger |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 84792 | Socket Sub-assy, Rear Window Defogger Switch |
| 84870A | Switch Assy, Outer Mirror |
| 84930 | Switch Assy, Door Control |
| 85336 | Switch Assy, Reserve Tank Level Warning |
| 85432 | Solenoid, Key Interlock |
| 85500 | Lighter Assy, Cigarette |
| 85500B | Bulb, Cigarette Lighter |
| 85500E | Plate, Voltage Caution |
| 85540 | Resistance Assy, Cigarette Lighter |
| 85550 | Resistor Assy, Pilot Lamp |
| 85909C | Bracket Sub-assy, Relay, NO.1 |
| 85909D | Bracket Sub-assy, Relay, NO.2 |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85910G | Relay, Heater Pump |
| 85910P | Relay, Turbo Indicator |
| 85912 | Relay, Defogger |
| 85915 | Relay, Main |
| 85916 | Relay, Light Control |
| 85924 | Relay, Ignition Control |
| 85931B | Relay, Fuel Heater |
| 85933 | Computer, Shift Lock Control |
| 85940 | Relay Assy, Windshield Wiper |
| 85959A | Holder, Relay |
| 85980 | Relay Assy, Door Control |
| 85996 | Cover, Combination Relay |
| 85997 | Cover, Relay Bracket |
| 85999A | Bracket, Relay, NO.2 |
| 85999C | Bracket, Relay, NO.3 |
| 85999D | Bracket, Relay, NO.4 |
| 85999E | Bracket, Relay, NO.5 |
| 85999H | Bracket, Relay |
| 85999R | Bracket, Relay, NO.6 |
| 85999X | Bracket, Relay, NO.7 |
| 86650 | Buzzer Assy, Vacuum Indicator |
| 86650A | Buzzer Assy, Door Opening |
| 86651 | Buzzer Assy, Back |
| 86690 | Buzzer Assy, Speed Indicator |
| 87280 | Switch Assy, Heter Pump |
| 87280B | Bulb (FOR HEATER PUMP SWITCH) |
| 87290 | Switch Assy, Heater |
| 87290B | Bulb (FOR HEATER SWITCH) |
| 88610L | Switch Assy,Control |
| 88630G | Relay Assy, Cooler |
| 88630H | Relay Assy, Cooler |
| 88630P | Relay, Cool Box |
| 89371 | Relay, Lamp Failure Indicator |
| 89422A | Sensor, Water Temperature |
| 89492 | Sensor, Electrolyte Level |
| 89550 | Computer Assy, Emission Control |
| 89590 | Computer Assy, Condition Indicator |
| 89593 | Sensor, Air Cleaner Warning |
| 89620 | Igniter Assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
