Toyota Coaster

2017-01 → present · chassis GDB1#,60,70,80,XZB60,70,80 · catalogue 811140 · Japan

Supported model Data version 2023-05

Caution Plate

40 part groups · 6 illustrations

PNC	Description
11285A	Label, Coolant System Notice
11293D	Label, Engine Caution
11296D	Label, Engine Service Information
17792D	Label, Emission Control Device Information
17792E	Label, Emission Control Device Information
35518	Plate, Automatic Transmission Caution, NO.2
35519	Plate, Automatic Transmission Caution
47288	Label, Brake Fluid Notice
47919A	Label, Brake System Information
73794	Label, Rear Seat Belt Notice
74511B	Plate, Name
74511F	Label, Name (IDENTIFICATION LASER LABEL)
74517	Plate, Exhaust Temperature Caution
74525A	Plate, Glide Door Caution
74531C	Plate, Door Inside Handle Caution
74535L	Label, Emergency Back Door Inner Caution
74538C	Label, Emergency Exit Caution
74538F	Label, Emergency Exit Caution, NO.2
74541H	Plate, Body Caution
74543L	Label, Rear Seat Caution, NO.1
74544D	Plate, Tire Carrier Caution
74545	Plate, Fixed Number Caution
74548	Plate, Body Caution
74552	Plate, Safety Caution
74552A	Label, Safety Caution
74552B	Label, Safety Caution
74553A	Plate, Front Seat Caution
74559B	Label, Fuel Information
74561A	Label, Fuel Consumption Information
74562B	Label, Emission Information
74568A	Plate, Front Slide Door Caution, NO.2
74751	Label, Tire Pressure Information
82683C	Label, Fuse Block Notice
85628L	Label, Automatic Door, NO.2
85628M	Label, Automatic Door, NO.3
85628N	Label, Automatic Door, NO.4
85628P	Label, Automatic Door, NO.5
86995E	Label, Caution
88723H	Label, Cooler Service Caution
89176A	Label, Airbag Deployment Information

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
