Toyota Pixis Van
2021-12 → present · chassis S700M,S710M · catalogue 894120 · Japan
Supported model
Data version 2024-11
Instrument Panel & Glove Compartment
49 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 51960B | Hook Assy, Front |
| 55046A | Panel Sub-assy, Instrument Panel Finish, Lower LH |
| 55063 | Register Sub-assy, Instrument, NO.3 |
| 55064A | Register Sub-assy, Instrument, NO.4 |
| 55301 | Panel Sub-assy, Instrument |
| 55302 | Panel Sub-assy, Center Control |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55315A | Spacer, Instrument Panel, NO.1 |
| 55330C | Plug, Hole(FOR INSTRUMENT PANEL) |
| 55331 | Reinforcement, Instrument Panel |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55374A | Bracket, Instrument Panel Lower Mounting, RH |
| 55394B | Bolt, Instrument Panel |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55406D | Clip(FOR PANEL, INSTRUMENT CLUSTER FINISH) |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55412E | Clip, Panel, Instrument Cluster Finish, End |
| 55421B | Panel, Instrument Cluster Finish, Upper |
| 55432D | Panel, Instrument Panel Finish, Lower NO.1 |
| 55446A | Base, Switch Hole, NO.1 |
| 55448B | Cover, Oil Reservoir Tank, RH |
| 55453E | Pad, Instrument, Lower RH |
| 55454C | Pad, Instrument, Lower LH |
| 55458E | Clip(FOR INSTRUMENT LOWER COVER) |
| 55479C | Clip(FOR INSTRUMENT LOWER COVER) |
| 55522F | Cover, Radio Tuner Opening |
| 55539 | Cover, Spare Switch Hole |
| 55539D | Cover, Spare Switch Hole |
| 55539E | Cover, Spare Switch Hole |
| 55539F | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55551A | Door, Glove Compartment, Outer |
| 55557A | Cushion, Glove Compartment Door Check |
| 55560A | Lock Assy, Glove Compartment Door |
| 55581A | Compartment, Glove |
| 55590 | Plate Assy, Grove Compartment Door Lock Striker |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55618C | Holder, Instrument Panel Cup |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55699 | Knob, Instrument Panel Register Control |
| 55699A | Knob, Instrument Panel Register Control NO.2 |
| 58811F | Box, Consol |
| 58811G | Clip(CONSOL BOX) |
| 58833D | Clip(FOR CONSOLE COVER) |
| 58848B | Cover, Shift Lever Hole |
| 73970A | Airbag Assy, Instrument Panel Passenger |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
