Toyota Pixis Truck
2011-11 → 2014-07 · chassis S201U,S211U · catalogue 897110 · Japan
Supported model
Data version 2015-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| 90048-51189 note |
Plug, Spark
2011-12 → 2012-09
ended
|
KFVE S201,211 | ¥830 | |
| 90048-51192 note |
Plug, Spark
2011-12 → 2012-09
ended
|
KFVE S201,211 | ¥830 | |
| 90048-51211 note |
Plug, Spark
2012-09 → 2012-11
ended
|
KFVE S201,211 | ¥830 | |
| 90048-51211 note |
Plug, Spark
2012-11 → 2014-07
ended
|
KFVE S201,211 | ¥830 | |
| 90048-51212 note |
Plug, Spark
2012-09 → 2012-11
ended
|
KFVE S201,211 | ¥830 | |
| 90048-51212 note |
Plug, Spark
2012-11 → 2014-07
ended
|
KFVE S201,211 | ¥830 | |
| 19500 — Coil Assy, Ignition | ||||
| 19500-B2050 note |
Coil Assy, Ignition
2011-12 → —
|
KFVE S201,211 | ¥7,800 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
