Toyota Pixis Truck
2011-11 → 2014-07 · chassis S201U,S211U · catalogue 897110 · Japan
Supported model
Data version 2015-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81700 — Lamp Assy, Work | ||||
| 81780-97502 note |
Lamp Assy, Work
2011-12 → 2013-04
ended
|
S201,211 SPL | ¥3,510 | |
| 81780-97502 |
Lamp Assy, Work
2011-12 → 2014-07
ended
|
S201,211 EXT | ¥3,510 | |
| 81780-97502 note |
Lamp Assy, Work
2013-04 → 2014-07
ended
|
S211 MTM SPL | ¥3,510 | |
| 81700B — Bulb, Work Lamp | ||||
| 99132-11210 note |
Bulb, Work Lamp
2011-12 → 2013-04
ended
|
S201,211 SPL | ¥170 | |
| 99132-11210 note |
Bulb, Work Lamp
2011-12 → —
|
S201,211 EXT | ¥170 | |
| 99132-11210 note |
Bulb, Work Lamp
2013-04 → —
|
S211 MTM SPL | ¥170 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
