Toyota Pixis Truck
2011-11 → 2014-07 · chassis S201U,S211U · catalogue 897110 · Japan
Supported model
Data version 2015-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 88301 — Rotor Sub-assy, Magnet Clutch | ||||
| 88412-B5020 note |
Rotor Sub-assy, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88412-B5020 |
Rotor Sub-assy, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88302B — Stator, Magnet Clutch | ||||
| 88411-87264 |
Stator, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88411-87264 note |
Stator, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88320 — Compressor Assy, Cooler | ||||
| 88320-B5020 |
Compressor Assy, Cooler
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88320-B5020 note |
Compressor Assy, Cooler
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88330A — Washer (FOR MAGNET CLUTCH) | ||||
| 88318-87704 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 EXT | ¥0 | |
| 88318-87704 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 SPL | ¥0 | |
| 88318-87705 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 EXT | ¥0 | |
| 88318-87705 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 SPL | ¥0 | |
| 88318-87706 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 EXT | ¥0 | |
| 88318-87706 note |
Washer (FOR MAGNET CLUTCH)
2011-12 → 2014-09
ended
|
S201,211 SPL | ¥0 | |
| 88365 — Ring, Snap | ||||
| 90099-07125 note |
Ring, Snap
2011-12 → 2014-09
ended
|
S201,211 SPL | ¥250 | |
| 90099-07125 |
Ring, Snap
2011-12 → 2014-09
ended
|
S201,211 EXT | ¥250 | |
| 88365A — Ring, Snap (FOR COMPRESSOR) | ||||
| 88365-87201 |
Ring, Snap (FOR COMPRESSOR)
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88365-87201 note |
Ring, Snap (FOR COMPRESSOR)
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88403 — Hub Sub-assy, Magnet Clutch | ||||
| 88403-97201 |
Hub Sub-assy, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88403-97201 note |
Hub Sub-assy, Magnet Clutch
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88410 — Clutch Assy, Magnet | ||||
| 88410-B5020 |
Clutch Assy, Magnet
2011-12 → 2014-09
ended
|
S201,211 EXT | ¥24,600 | |
| 88410-B5020 note |
Clutch Assy, Magnet
2011-12 → 2014-09
ended
|
S201,211 SPL | ¥24,600 | |
| 88431 — Bracket, Compressor Mounting, NO.1 | ||||
| 88431-B5030 |
Bracket, Compressor Mounting, NO.1
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88431-B5030 note |
Bracket, Compressor Mounting, NO.1
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88446C — Bolt, Magnet Clutch Setting | ||||
| 90099-04349 |
Bolt, Magnet Clutch Setting
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 90099-04349 note |
Bolt, Magnet Clutch Setting
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
| 88688K — Bracket, Cooler Compressor | ||||
| 88688-B5010 |
Bracket, Cooler Compressor
2011-12 → 2014-09
ended
|
S201,211 EXT | — | |
| 88688-B5010 note |
Bracket, Cooler Compressor
2011-12 → 2014-09
ended
|
S201,211 SPL | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
