Toyota Pixis Truck
2021-12 → present · chassis S500U,S510U · catalogue 897130 · Japan
Supported model
Data version 2021-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 35610A — Clutch Assy, Forward Multiple Disc | ||||
| 35610-B5010 |
Clutch Assy, Forward Multiple Disc
2021-12 → —
|
S500,510 CVT | ¥17,600 | |
| 35788F — Race, Thrust Bearing | ||||
| 35789-B5020 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
| 35789-B5030 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
| 35789-B5040 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
| 35789-B5050 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
| 35789-B5060 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
| 35789-B5070 note |
Race, Thrust Bearing
2021-12 → —
|
S500,510 CVT | ¥250 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
