Toyota Pixis Truck

2021-12 → present · chassis S500U,S510U · catalogue 897130 · Japan

Supported model Data version 2021-12

Side Member

35 part groups · 2 illustrations

PNC	Description
52143C	Bracket, Front Bumper Side, RH
52144C	Bracket, Front Bumper Side, LH
53271D	Bracket, Headlamp Mounting, RH
53272B	Bracket, Headlamp Mounting, LH
53837C	Bracket, Front Side Panel, NO.2 RH
53838E	Bracket, Front Side Panel, NO.2 LH
53878G	Spacer, Front Fender
61021C	Pillar Sub-assy, Front Body, RH
61022C	Pillar Sub-assy, Front Body, LH
61023B	Pillar Sub-assy, Front Body, Inner RH
61024B	Pillar Sub-assy, Front Body, Inner LH
61103G	Gusset Sub-assy, Front Body Pillar, Lower RH
61104G	Gusset Sub-assy, Front Body Pillar, Lower LH
61105B	Reinforce Sub-assy, Front Door Check, RH
61105C	Reinforce Sub-assy, Front Door Check, LH
61107	Pillar Sub-assy, Front Body Outer, RH
61108	Pillar Sub-assy, Front Body Outer, LH
61108A	Reinforce Sub-assy, Front Body Pillar, Lower RH
61111A	Panel, Front Side, Outer RH
61112A	Panel, Front Side, Outer LH
61133B	Bracket, Front Body Pillar ,Outer RH
61134B	Bracket, Front Body Pillar Outer, LH
61135	Reinforcement, Front Body Pillar, Upper RH
61136	Reinforcement, Front Body Pillar, Upper LH
61136B	Reinforcement, Front Body Pillar, Outer
61147A	Extension, Front Body Pillar, Upper Outer
61148A	Extension, Front Body Pillar, Upper Outer LH
61303	Reinforce Sub-assy, Center Body Pillar, Upper RH
61304	Reinforce Sub-assy, Center Body Pillar, Upper LH
61411D	Panel, Fender, Outer RH
61412D	Panel, Fender, Outer LH
62311A	Weatherstrip, Front Door Opening Trim, RH
62312A	Weatherstrip, Front Door Opening Trim, LH
62313H	Trim, Front Door Opening, RH
62314A	Trim, Front Door Opening, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
