Toyota Scion XB
2003-04 → 2006-12 · chassis NCP31 · catalogue 115410 · United States
Discontinued model
Data version 2007-06
Instrument Panel & Glove Compartment
33 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55061 | Register Sub-assy, Instrument Panel, NO.1 |
| 55301 | Panel Sub-assy, Instrument |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55308C | Bracket Sub-assy, Instrument Panel, Center |
| 55310 | Panel Assy, Instrument, Lower |
| 55331 | Reinforcement, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55358A | Protector, Edge, NO.2 |
| 55359D | Cushion, Instrument Panel, NO.5 |
| 55376 | Bracket, Instrument Panel Mounting, NO.1 |
| 55391 | Cushion, Instrument Panel, Lower NO.1 |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55414A | Panel, Instrument Cluster Finish, End |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55465C | Insert, Instrument Panel Lower Pad, LH |
| 55503B | Cushion(FOR GLOVE COMPARTMENT) |
| 55510 | Door Assy, Glove Compartment |
| 55510A | Cushion(FOR GLOVE COMPARTMENT DOOR) |
| 55539D | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55547E | Cover, Instrument Panel Hole, NO.3 |
| 55548A | Cover, Instrument Panel Hole |
| 55560A | Lock Assy, Glove Compartment Door |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55682 | Spring, Instrument Panel Register Support |
| 55950A | Nozzle Assy, Defroster |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 74599C | Label, Driver & Passenger Airbag Information |
| 89279J | Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
