Toyota Scion XA
2003-04 → 2006-12 · chassis NCP61 · catalogue 117410 · United States
Supported model
Data version 2007-06
Instrument Panel & Glove Compartment
31 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55061 | Register Sub-assy, Instrument Panel, NO.1 |
| 55301 | Panel Sub-assy, Instrument |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55310 | Panel Assy, Instrument, Lower |
| 55331 | Reinforcement, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55356C | Cushion, Instrument Panel, NO.2 |
| 55357B | Cushion, Instrument Panel, NO.3 |
| 55376 | Bracket, Instrument Panel Mounting, NO.1 |
| 55378A | Bracket, Glove Compartment Door Lock Mounting |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55406C | Insert Sub-assy, Instrument Panel, Lower LH |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55420A | Panel Assy, Instrument Cluster Finish, Center |
| 55432A | Panel, Instrument Panel Finish, Lower RH |
| 55433C | Panel, Instrument Panel Finish, Lower LH |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55465C | Insert, Instrument Panel Lower Pad, LH |
| 55474C | Garnish, Instrument Cluster Finish Panel, NO.1 |
| 55475A | Garnish, Instrument Cluster Finish Panel, NO.2 |
| 55479B | Cover, Instrument, Lower Center |
| 55503B | Cushion(FOR GLOVE COMPARTMENT) |
| 55539 | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55550 | Door Assy, Glove Compartment |
| 55560A | Lock Assy, Glove Compartment Door |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55682 | Spring, Instrument Panel Register Support |
| 55686 | Retainer, Register Blade |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 89279J | Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
