Toyota Scion XD
2007-06 → 2014-07 · chassis ZSP110 · catalogue 117420 · United States
Supported model
Data version 2015-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 69052 — Cylinder & Key Set, Door Lock, LH | ||||
| 69052-52360 note |
Cylinder & Key Set, Door Lock, LH
2013-05 → 2013-07
ended
|
ZSP110 CND | — | |
| 69052-52360 |
Cylinder & Key Set, Door Lock, LH
2007-06 → 2014-07
ended
|
ZSP110 | — | |
| 69052-52360 note |
Cylinder & Key Set, Door Lock, LH
2013-05 → 2013-07
ended
|
ZSP110 USA | — | |
| 69057A — Cylinder & Key Set, Ignition Switch Lock | ||||
| 69057-12770 |
Cylinder & Key Set, Ignition Switch Lock
2007-06 → 2012-08
ended
|
ZSP110 USA | — | |
| 69057-21180 note |
Cylinder & Key Set, Ignition Switch Lock
2013-05 → 2013-07
ended
|
ZSP110 CND | — | |
| 69057-35240 |
Cylinder & Key Set, Ignition Switch Lock
2010-08 → 2012-08
ended
|
ZSP110 CND | — | |
| 69057-52730 note |
Cylinder & Key Set, Ignition Switch Lock
2013-05 → 2013-07
ended
|
ZSP110 USA | — | |
| 69057-52B40 |
Cylinder & Key Set, Ignition Switch Lock
2012-08 → 2014-07
ended
|
ZSP110 CND | — | |
| 69057-52B90 |
Cylinder & Key Set, Ignition Switch Lock
2012-08 → 2014-07
ended
|
ZSP110 USA | — | |
| 69503 — Cylinder Set, Lock | ||||
| 69005-52E80 |
Cylinder Set, Lock
2007-06 → 2012-08
ended
|
ZSP110 USA | — | |
| 69005-52J00 |
Cylinder Set, Lock
2012-08 → 2014-07
ended
|
ZSP110 USA | — | |
| 69005-52M00 |
Cylinder Set, Lock
2010-08 → 2012-08
ended
|
ZSP110 CND | — | |
| 69005-52P20 |
Cylinder Set, Lock
2012-08 → 2014-07
ended
|
ZSP110 CND | — | |
| 89704-52J00 note |
Cylinder Set, Lock
2013-05 → 2013-07
ended
|
ZSP110 USA | — | |
| 89704-52J90 note |
Cylinder Set, Lock
2013-05 → 2013-07
ended
|
ZSP110 CND | — | |
| 69503A — Key, Blank | ||||
| 90999-00248 note |
Key, Blank
2007-06 → 2014-07
ended
|
ZSP110 USA | — | |
| 89070E — Transmitter Assy, Door Control | ||||
| 89070-21120 |
Transmitter Assy, Door Control
2007-06 → 2012-08
ended
|
ZSP110 USA | — | |
| 89070-21150 note |
Transmitter Assy, Door Control
2013-05 → 2013-07
ended
|
ZSP110 CND | — | |
| 89070-21180 |
Transmitter Assy, Door Control
2010-08 → 2012-08
ended
|
ZSP110 CND | — | |
| 89070-52G20 |
Transmitter Assy, Door Control
2012-08 → 2014-07
ended
|
ZSP110 USA | — | |
| 89070-52G30 |
Transmitter Assy, Door Control
2012-08 → 2014-07
ended
|
ZSP110 CND | — | |
| 89070-74110 note |
Transmitter Assy, Door Control
2013-05 → 2013-07
ended
|
ZSP110 USA | — | |
| 89070F — Transmitter Assy, Door Control (CUT KEY) | ||||
| 89070-21170 note |
Transmitter Assy, Door Control (CUT KEY)
2013-05 → 2013-07
ended
|
ZSP110 CND | — | |
| 89070-74120 note |
Transmitter Assy, Door Control (CUT KEY)
2013-05 → 2013-07
ended
|
ZSP110 USA | — | |
| 89071B — Module Set, Transmitter Sub-assy, Door Control | ||||
| 89071-21020 |
Module Set, Transmitter Sub-assy, Door Control
2007-06 → 2012-08
ended
|
ZSP110 | — | |
| 89071-52290 |
Module Set, Transmitter Sub-assy, Door Control
2012-08 → 2014-07
ended
|
ZSP110 | — | |
| 89072A — Housing Set, Door Control Transmitter | ||||
| 89072-21090 |
Housing Set, Door Control Transmitter
2007-06 → 2012-08
ended
|
ZSP110 USA | — | |
| 89072-21150 |
Housing Set, Door Control Transmitter
2010-08 → 2012-08
ended
|
ZSP110 CND | — | |
| 89072-52A20 |
Housing Set, Door Control Transmitter
2012-08 → 2014-07
ended
|
ZSP110 USA | — | |
| 89072-52A30 |
Housing Set, Door Control Transmitter
2012-08 → 2014-07
ended
|
ZSP110 CND | — | |
| 8907A — Switch Set, Transmitter | ||||
| 8907A-21010 |
Switch Set, Transmitter
2007-06 → 2012-08
ended
|
ZSP110 | — | |
| 8907A-52020 |
Switch Set, Transmitter
2012-08 → 2014-07
ended
|
ZSP110 | — | |
| 89745A — Battery, Transmitter | ||||
| 89745-12010 note |
Battery, Transmitter
2013-05 → 2013-07
ended
|
ZSP110 | — | |
| 89745-71010 note |
Battery, Transmitter
2007-06 → 2014-07
ended
|
ZSP110 | — | |
| 89751A — Cover, Transmitter Housing | ||||
| 89751-12070 note |
Cover, Transmitter Housing
2013-05 → 2013-07
ended
|
ZSP110 | — | |
| 89751-21030 |
Cover, Transmitter Housing
2007-06 → 2012-08
ended
|
ZSP110 | — | |
| 89751-52270 |
Cover, Transmitter Housing
2012-08 → 2014-07
ended
|
ZSP110 | — | |
| 89752A — Case, Transmitter Housing | ||||
| 89752-52130 |
Case, Transmitter Housing
2012-08 → 2014-07
ended
|
ZSP110 CND | — | |
| 89752-52210 |
Case, Transmitter Housing
2012-08 → 2014-07
ended
|
ZSP110 USA | — | |
| 89752-68060 |
Case, Transmitter Housing
2010-08 → 2012-08
ended
|
ZSP110 CND | — | |
| 89752-71080 |
Case, Transmitter Housing
2007-06 → 2012-08
ended
|
ZSP110 USA | — | |
| 89758 — Packing, Door Control Transmitter | ||||
| 89758-12010 note |
Packing, Door Control Transmitter
2013-05 → 2013-07
ended
|
ZSP110 | — | |
| 89786B — Transmitter, Transponder Key Sub | ||||
| 89786-12100 note |
Transmitter, Transponder Key Sub
2010-08 → 2014-07
ended
|
ZSP110 CND | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
