Toyota Scion XD
2007-06 → 2014-07 · chassis ZSP110 · catalogue 117420 · United States
Supported model
Data version 2015-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87245A — Hose, Heater Water, Inlet A | ||||
| 87245-52141 |
Hose, Heater Water, Inlet A
2007-06 → 2014-07
ended
|
ZSP110 | — | |
| 87246A — Hose, Heater Water, Outlet A | ||||
| 87245-52151 |
Hose, Heater Water, Outlet A
2007-06 → 2014-07
ended
|
ZSP110 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
