Toyota Yaris GR
2020-08 → present · chassis GXPA16 · catalogue 11E210 · United States
Supported model
Data version 2024-10
Caution Plate (EXTERIOR & INTERIOR)
16 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 11285A | Label, Coolant System Notice |
| 11285F | Label, Coolant System Caution |
| 11291B | Plate, Engine Name |
| 11293D | Label, Engine Caution |
| 11298B | Label, Emission Control Information |
| 16793E | Label, Cooling Fan Caution |
| 41992 | Label, Differential Notice |
| 41992A | Label, Differential Notice, NO.2 |
| 42661 | Label, Tire Pressure Information |
| 47288 | Label, Brake Fluid Notice |
| 74511F | Label, Name (IDENTIFICATION LASER LABEL) |
| 74515C | Label, Theft Warning Information |
| 74559B | Label, Fuel Information |
| 88723E | Label, Cooler Service Caution |
| 88723H | Label, Cooler Service Caution |
| 89356A | Label, Clearance Warning Information |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
